WR01F04643, 200D1181G108

CWE19SP2NKS1, CWE19SP2NLS1, CWE19SP2NNS1, CWE19SP3NKD1, CWE19SP3NND1, CWE19SP4NKW2, CWE19SP4NNW2, GDE21EGKPRBB, GDE21EGKPRWW, GDE21EMKNRES, GDE21EMKPRES, GDE21ESKLRSS, GDE21ESKNRSS, GDE21ESKPRSS, GDE21ESKRRSS, GDE21EYKBRFS, GDE25ESKLRSS, GDE25ESKNRSS, GDE25ESKPRSS, GDE25EYKBRFS, GNE21FMKNFES, GNE21FSKNFSS, GNE21FYKBFFS, GNE25JGKNFBB, GNE25JGKNFWW, GNE25JMKNFES, GNE25JSKNFSS, GNE25JYKBFFS, GNE27ESMKFSS, GNE27EYMKFFS, GNE27EYMNFFS, GNE27JGMKFBB, GNE27JGMKFWW, GNE27JGMNFBB, GNE27JGMNFWW, GNE27JMMKFES, GNE27JMMNFES, GNE27JMMPFES, GNE27JSMDFSS, GNE27JSMKFSS, GNE27JSMNFSS, GNE27JYMKFFS, GNE27JYMNFFS, GWE19JGLKFBB, GWE19JGLKFWW, GWE19JGLNFBB, GWE19JGLNFWW, GWE19JMLKFES, GWE19JMLNFES, GWE19JMLPFES, GWE19JSDKFSS, GWE19JSLDFSS, GWE19JSLKFSS, GWE19JSLNFSS, GWE19JSLPFSS, GWE19JYLBFFS, IDM25ESKJCSS, INM25FSKJCSS, MDU25ESKJCSS, MDU25ESKLCSS, PDE21KGKJKWW, PDE21KMKJKES, PDE21KSKJKSS, PDM21ESKJCSS, PDM25ESKJCSS, PNE21NGLJKWW, PNE21NGLLKWW, PNE21NGLNKWW, PNE21NMLJKES, PNE21NMLLKES, PNE21NMLNKES, PNE21NSLJKSS, PNE21NSLLKSS, PNE21NSLNKSS, PNE21NYRBKFS, PNE25NGLJKBB, PNE25NGLJKWW, PNE25NGLLKBB, PNE25NGLLKWW, PNE25NGLNKBB, PNE25NGLNKWW, PNE25NMLLKES, PNE25NMLNKES, PNE25NSLLKSS, PNE25NSLNKSS, PNE25NYRBKFS, PNM27ESMKFSS, PNM27JSMKTSS, PWM19JSLBFSS, QNE27JBMKFTS, QNE27JBMNFTS, QNE27JSMKFSS, QNE27JSMNFSS, XNE25JSKNFSS

Tools Needed

•
  Phillips screwdriver

•
  Nut driver (usually 1/4" or 5/16")

•
  Needle-nose pliers (optional)

•
  Towel or small container (to catch water)


Step-by-Step Installation

1.
   Unplug the Refrigerator

   Safety first! Always disconnect power before working on electrical components.

2.
   Turn Off Water Supply

   Shut off the water line to the ice maker to prevent leaks.

3.
   Remove Ice Bin

   Slide out the ice storage bin to access the ice maker assembly.

4.
   Detach Old Ice Maker


   Locate the mounting screws at the top and/or side.


   Unscrew and gently pull the ice maker forward.


   Disconnect the wiring harness (press tab and pull) and the water inlet tube.



5.
   Prepare New Ice Maker


   Compare the new WR01F04812 with the old one to ensure compatibility.


   Make sure the ice mold and control arm move freely.



6.
   Connect Water Supply & Wiring


   Attach the water inlet tube to the new ice maker (ensure snug fit to prevent leaks).


   Connect the wiring harness firmly until it clicks into place.



7.
   Mount Ice Maker


   Position the ice maker back into place.


   Secure it with screws removed earlier.


   Ensure the assembly is level for proper ice formation.



8.
   Replace Ice Bin

   Slide the ice bin back into its position.

9.
   Turn On Water Supply

   Slowly turn on water to the ice maker and check for leaks.

10.
    Plug In Refrigerator & Test


    Plug the refrigerator back in.


    Manually cycle the ice maker if possible (refer to your fridge manual) to ensure it produces ice correctly.




Tips & Warnings

•
  Avoid using excessive force when connecting the water line to prevent cracking the fitting.

•
  If ice production is slow, check that the water inlet valve is supplying adequate pressure.

•
  Keep fingers clear of the ice mold during the first automatic cycle.

•
  Some models require resetting the ice maker after installation; consult your fridge manual for reset instructions.

1. No Ice Production

•
  Ice maker does not cycle or produce ice.

•
  Could be due to a faulty ice maker, water inlet valve, or control board.


2. Ice Maker Not Filling with Water

•
  Ice tray remains empty.

•
  Often caused by a clogged or frozen water line, or defective water inlet valve.


3. Partial or Small Ice Cubes

•
  Ice cubes are smaller than usual or misshapen.

•
  Could indicate low water pressure, partially clogged inlet, or malfunctioning mold heater.


4. Ice Maker Continuously Runs

•
  Ice maker keeps trying to produce ice without stopping.

•
  Commonly caused by a stuck or broken shut-off arm, faulty thermostat, or defective control module.


5. Ice Jam or Overflow

•
  Ice cubes stuck in the ejector mechanism or bin overflows.

•
  Could result from misaligned ice maker, ice mold damage, or failure to eject cubes properly.


6. Leaks Around Ice Maker

•
  Water pooling under ice bin or on refrigerator floor.

•
  Usually caused by loose water line connection, cracked ice mold, or faulty inlet valve.


7. Strange Noises

•
  Clicking, buzzing, or grinding noises during ice production.

•
  Could indicate mechanical issues with the ejector motor or mold heater.


💡 Tip: Many of these issues can be diagnosed by checking the water supply, electrical connections, and the control arm/motor operation before replacing the ice maker.
