WR01F04812 GE Ice Maker Assembly for Refrigerators, Fixes No Ice or Slow Ice Production

The GE WR01F04812 is a genuine GE Appliances / Mabe refrigerator ice-maker assembly. It replaces former service numbers WR01F04276, WR01F04643, WR03F04454 and WR03F04468. The assembly contains the ice mold and operating mechanism responsible for receiving water, freezing it, and ejecting completed cubes into the ice bin.

A failed assembly may cause no ice production, slow or intermittent ice production, cubes remaining in the mold, or an ejector mechanism that does not complete its cycle. Similar symptoms can result from a freezer that is too warm, a frozen fill tube, low water pressure, a failed inlet valve, damaged wiring, a disabled ice maker, or a refrigerator control problem. Confirm the complete refrigerator model before ordering.

WR30X35287 is a related U.S. regional service number and should not be described as a Canadian OEM predecessor.

Is This the Right Part?

Confirm the complete model number, including suffixes and revision digits, before ordering. Similar parts may use different connectors, dimensions, hose positions, electrical ratings, or mounting points. One verified purchaser reported that a component had to be transferred from the original assembly — compare the replacement with the original before installation.

Common Symptoms

• No ice production
• Intermittent or unusually slow ice production
• Ice cubes remaining in the mold after a cycle
• Ejector mechanism not completing its cycle
• Ice maker fills with water but does not harvest cubes
• Mechanical clicking or grinding from the ice-maker assembly

Check Before Replacing

• Verify the freezer is at or below 0°F / -18°C — a warm freezer prevents ice formation regardless of ice maker condition
• Confirm the water supply line is connected, not kinked, and water pressure is adequate
• Check that the ice maker is switched on and the shutoff arm or sensor is not in the off position
• Inspect the fill tube for ice blockages that restrict water delivery to the mold
• Test the water inlet valve — a partially failed valve restricts flow and can cause hollow cubes or underfilling
• Check wiring harness connections at the ice maker for damage or looseness

Part Details

Installation Notes

1. Disconnect refrigerator power and shut off the water supply before service.
2. Photograph wiring harness connections, fill tube routing, and mounting positions before removal.
3. Compare the replacement assembly with the original part before installation — component transfer from the original may be required.
4. Follow the model-specific service procedure for your refrigerator and installed ice-maker configuration.
5. Inspect nearby wires, the fill tube, and the inlet valve for damage while the panel is open.
6. Use the testing or reset procedure specified for the refrigerator model and installed ice-maker configuration — procedures vary by model.
7. Allow adequate time for the first full production cycle before evaluating results.

Use a qualified technician when diagnosis or installation is outside your experience.

Verified Compatible Models

CFE24SSKAKSS, PFE24JSKAKSS

Fitment reminder: Match the complete model number, including suffixes and revision digits, before ordering. The model list above reflects models verified under the two-independent-source standard for this audit. Additional models may be compatible — contact us with your full model number to confirm before ordering.
