Oven Burner or Element Not Heating? Receptacle Assembly WS01L06890 – Fix No Power Fast
If your GE oven has a burner or bake/broil element that won't heat, glows only partially, or has visible arcing or burn marks at the connection point, the receptacle assembly is the most common cause. In most GE electric ranges and wall ovens, this is caused by a failed element receptacle assembly. When it fails, the element loses its electrical connection — resulting in no heat, partial heating, tripped breakers, or visible burning at the terminal block. ⚡ Common failure point in GE-built electric ranges and wall ovens. Part WS01L06890 is the OEM replacement receptacle assembly that restores a clean, secure electrical connection and eliminates heating faults.
❓ Is This the Right Part?
This is the correct fix if ALL of the following are true:
- ✔ Oven powers on and control panel responds normally
- ✔ Other elements or burners in the oven heat correctly
- ✔ Household breaker is not tripped — power supply confirmed OK
- ✔ ONLY problem is one element not heating, arcing at the connection, or a burnt/melted receptacle socket
Not sure? Send us your model number — we'll confirm before you order.
🔧 Common Symptoms
- Bake or broil element not heating at all
- Element heats only partially or on one side
- Visible burn marks, melting, or arcing at the element connection point
- Burning smell from the back of the oven cavity
- Breaker trips when oven is turned on
- Element terminal loose, corroded, or won't seat securely
✔ If these symptoms match, this is the most likely failed component in the system.
✔ In most cases, replacing this receptacle assembly restores full heating function immediately.
📦 Part Details
- Part Number: WS01L06890
- Type: Oven Element Receptacle Assembly — terminal block and wiring harness that connects the heating element to the oven's electrical supply
- Replaces: WS01L06890
- Brands: GE, Hotpoint, RCA
If the receptacle shows burn damage, inspect the bake or broil element itself before reinstalling. A shorted element is often what causes the receptacle to burn out in the first place — installing a new receptacle on a failed element will destroy the new part quickly. Replace both together if the element shows any cracks, holes, or blistering.
⚙️ Installation
Skill Level: Easy — 15 to 25 minutes. Disconnect power at the breaker before servicing — do not rely on the oven's power switch alone. Pull the oven away from the wall and remove the back panel to access the receptacle block. Disconnect the wiring harness from the old receptacle, unscrew the mounting bracket, and install the new assembly in reverse order. Reconnect the element, restore power, and test both bake and broil functions.
✓ Compatible Models
Compatible with select GE, Hotpoint, and RCA electric ranges and wall ovens. Contact us to verify your model number before ordering.
💡 Pro Tip
A burnt receptacle is almost always caused by a failing element drawing excess current through a loose or corroded terminal. If you replace only the receptacle without inspecting the element, the new receptacle will fail again within months. Pull the element, check for cracks or blistering, and test continuity with a multimeter. If resistance is out of spec or the element shows physical damage, replace both parts at the same time.
