GE Washer Top Load Tub Assembly WW01A00813 — Fix Leaking, Seized or Noisy Washer Tub

When a GE top-load washer leaks from the bottom, grinds loudly during spin, or stops agitating entirely, the tub assembly is the most common root cause. In GTW, HTW, and MTW series washers, a cracked outer tub or failed integrated bearings allows water to escape the drum and saturate the motor and drive components — causing cascading damage if left unaddressed. ⚡ Replacing the tub assembly immediately stops the leak and prevents further water damage to your laundry room and machine. Part WW01A00813 is the current genuine OEM replacement that delivers a direct factory-fit installation with no modification required, superseding both WW01A00735 and 233D3158G002.

❓ Is This the Right Part?

This is the correct fix if ALL of the following are true:

• ✔ You have a GE, Hotpoint, or Maytag top-load washer (GTW, HTW, or MTW series)
• ✔ Your model number is listed in the compatible models section below
• ✔ The washer is leaking, making loud grinding or rumbling noise, or not agitating or spinning
• ✔ You have confirmed the tub itself is cracked, corroded, or the bearings have failed
• ✔ ONLY problem is the tub assembly — motor, pump, and lid switch have been ruled out

🔧 Common Symptoms

• Water leaking from the bottom of the washer during wash or spin cycle
• Loud grinding, rumbling, or banging noise during operation
• No agitation or weak agitation during the wash cycle
• Tub not spinning or spinning at reduced speed
• Visible cracks or damage to the inner or outer tub
• Rust stains on clothes or corrosion visible on the tub interior

✔ If these symptoms match, the tub assembly is the most likely failed component in the system.

✔ In most cases, replacing this tub assembly restores normal wash operation immediately.

📦 Part Details

• Part Number: WW01A00813
• Type: Top Load Washer Tub Assembly — complete unit (inner tub, outer tub, bearings, and hardware)
• Replaces: WW01A00735, 233D3158G002 — no modification required
• Brands: GE, General Electric, Hotpoint, Maytag, Westinghouse, Monogram, Café, Moffat, Profile, Sears
• Weight: Approximately 75 lbs — two-person installation strongly recommended

⚙️ Installation Notes

Skill Level: Advanced (5/5) — 3 to 6 hours. Disconnect power and shut off water supply before beginning any disassembly. Remove the cabinet panels and control panel, then disconnect the motor, pump, transmission, and all hose connections before lifting the tub assembly out. Photograph all wire harness connections and hose routing before removal. Drain all water from the machine before tipping or laying the unit on its side. Two people are required to safely handle and position this 75 lb assembly. Run a full test cycle with no laundry after installation to confirm no leaks before returning the machine to service.

💡 Pro Tip

GTW220BMK0WW, GTW220BMK1WW, GTW220BMM0WW, GTW302BMP0WW, GTW330BMK0WW, GTW330BMK1WW, GTW331BMR0WS, HTW200BMK0WW, HTW200BMM0WW, MTW200BMK0WW, MTW200BMM0WW, MTW200BMM1WW, MTW201BMR0WW
