Dryer Not Spinning? Idler Pulley Assembly 134793511 – Fix Belt Tension Loss Fast

Name: Frigidaire Dryer Idler Pulley Assembly 134793511 – OEM & XPart Replacement
Brand: Frigidaire
SKU: 134793511
Price: 49.99 CAD
Availability: OutOfStock

A failed idler pulley assembly doesn't just make noise — it kills drum rotation entirely, leaving clothes soaking wet and your dryer useless. In most Frigidaire-built dryers, this is caused by a failed idler arm and pulley assembly. When it fails, the drive belt loses tension, the drum stops turning, and the dryer runs heat with no airflow — a fire risk if left unaddressed. ⚡ Common failure point in Frigidaire-built dryers. Part 134793511 is the genuine OEM replacement that restores correct belt tension and drum rotation immediately.

❓ Is This the Right Part?

This is the correct fix if ALL of the following are true:

✔ Dryer powers on and motor runs normally
✔ Heating element and controls work correctly
✔ Power supply and door switch confirmed OK
✔ ONLY problem is drum not spinning, squealing, or belt slipping off

Not sure? Send us your model number — we'll confirm before you order.

🔧 Common Symptoms

Dryer drum not rotating at all (no drum movement)
Squealing, squeaking, or thumping noises during operation
Drive belt slipping off or losing tension
Drum rotating slowly or intermittently
Dryer taking longer than normal to dry clothes
Drum stopping mid-cycle
Visible flat spots, cracks, or wear on the pulley wheel
Idler arm loose or wobbly when drum is manually rotated

✔ If these symptoms match, this is the most likely failed component in the system.

✔ In most cases, replacing this idler pulley assembly restores normal drum operation immediately.

📦 Part Details

Part Number: 134793511
Type: Idler Arm & Pulley Assembly (Belt Tensioner)
Replaces: 134793500, 134793512, 7134793500
Brands: Frigidaire, Electrolux, Gibson, Kenmore, White-Westinghouse, Kelvinator, Tappan

⚠️ Recommended While Repairing:
The idler pulley and drive belt wear together. If your pulley has failed, inspect the belt for fraying, glazing, or cracking — a worn belt on a new pulley causes premature failure and a second labour call. Drum support rollers are also worth checking at the same time. Replacing all three in one visit is the professional standard.

⚙️ Installation

Skill Level: MODERATE — 45–60 min DIY / 30–45 min professional. Disconnect power before servicing. Remove the front or rear panel to access the idler assembly at the base of the cabinet. Photograph belt routing before removal — critical for correct reassembly. Route belt around drum → under idler pulley → around motor pulley. Test belt tension after install: belt should deflect ~0.5–1 inch under moderate pressure.

✓ Compatible Models

Confirmed compatible with 41781100000, 41781101000, 41781102000, BAQE7073KW0, BAQE7077KB0, CAQE7001LW0, CAQE7011KB0, CAQE7011KW0, EFME427UIW0, EFME527UIW0, EFME627UIW0, FAQE7001LW0, FAQE7011KW0, FAQE7077KW0, FAQG7001LW0, FAQG7077KW0, ELFE7337AW0, ELFE7637AW0, ELFG7637AW0, EIMED60JIW0, EIMGD60JIW0 plus hundreds of additional Frigidaire, Electrolux, Gibson, Kenmore, and White-Westinghouse models. Contact us to verify your model number before ordering.

💡 Pro Tip

Replace the Belt While You're In There:
The idler pulley and drive belt wear together. A worn belt on a new pulley will cause premature failure and a second labour call. Drum support rollers are also worth inspecting at the same time — replacing all three in one visit is the professional standard and saves significant labour cost on a repeat repair.

✅Compatibility & Cross Reference

Idler Arm Assembly, Idler Pulley, Drum Idler, Belt Tensioner, Idler Wheel Assembly, Drum Support Idler

Part number 134793511 replaces 134793500, 134793512, 7134793500

41781100000, 41781101000, 41781102000, 41781122310, 41781122311, 41784130000, 41784131000, 41784132000, 41788022000, 41791100000, 41791101000, 41791102000, 41791122310, 41791122311, 41794130000, 41794131000, 41794132000, 41794132002, 41798022000, BAQE7073KW0, BAQE7077KB0, BAQE7077KW0, BAQG7073KW0, BAQG7077KB0, BAQG7077KW0, BKQE7017KT0, BKQE7071MT0, CAQE7001LW0, CAQE7001LW1, CAQE7011KB0, CAQE7011KW0, CAQE7011LW0, CAQE7014KA0, CAQE7014KN0, CAQE7017KW0, CAQE7021LW0, CAQE7021LW1, CAQE7072LA0, CAQE7072LR0, CAQE7072LW0, CAQE7073KB0, CAQE7073KW0, CAQE7077KA0, CAQE7077KB0, CAQE7077KN0, CAQE7077KR0, CAQE7077KW0, CARE1011MW0, CARE1011MW1, CARE4044MW0, Dryer - DRYER, CARE4044MW1, CASE7021NW0, CASE7021NW2, CASE7021NW3, CASE7073LA0, CASE7073LR0, CASE7073LW0, CASE7074NA0, CASE7074NA2, CASE7074NA3, CASE7074NR0, CASE7074NR2, CASE7074NR3, CASE7074NW0, CASE7074NW2, CASE7074NW3, CDE4500KW0, CDE4700LB0, CDE4700LW0, CDE4700LW1, CDE4701QW0, CDE7300RW0, CDE7400QW0, CDE7400QW1, CDE7500KB0, CDE7500KR0, CDE7500KW0, CDE7700LR0, CDE7700LW0, CDE7700LW1, CDEC450KW0, CDEC750KW0, CDG4500KW0, CDG4700LB0, CDG4700LW0, CDG4700LW1, CDG4701QW0, CDG7300RW0, CDG7300RW1, CDG7400QW0, CDG7500KB0, CDG7500KR0, CDG7500KW0, CDG7700LW0, CDG7700LW1, CFQE4000QW0, CFQE5000QW0, CFQE5000QW1, CFQE5100PW0, CFQE5100PW1, CFQE5100PW2, CFQE5100PW3, CFRE1001PW0, CFSE5100QA0, CFSE5115PA0, CFSE5115PA1, CFSE5115PW0, CFSE5115PW1, DAQE7077KW0, DAQG7077KW0, EFDC317TIW0, EFDC317TIW1, EFDC317TIW2, EFDC317TIW3, EFDE317TIW0, EFDE317TIW1, EFDE317TIW2, EFDE317TIW3, EFDG317TIW0, EFDG317TIW1, EFDG317TIW2, EFMC417SIW0, EFMC427UIW0, EFMC427UIW1, EFMC427UIW2, EFMC517SIW0, EFMC517STT0, EFMC527UIW0, EFMC527UIW1, EFMC527UIW2, EFMC527UTT0, EFMC527UTT1, EFMC527UTT2, EFMC617SIW0, EFMC617STT0, EFMC627UIW0, EFMC627UIW1, EFMC627UIW2, EFMC627UTT0, EFMC627UTT1, EFMC627UTT2, EFME417SIW0, EFME427UIW0, EFME427UIW1, EFME427UIW2, EFME517SIW0, EFME517STT0, EFME527UIW0, EFME527UIW1, EFME527UIW2, EFME527UTT0, EFME527UTT1, EFME527UTT2, EFME617SIW0, EFME617STT0, EFME627UIW0, EFME627UIW1, EFME627UIW2, EFME627UTT0, EFME627UTT1, EFME627UTT2, EFME628WTT00, EFMG417SIW0, EFMG427UIW0, EFMG427UIW1, EFMG517SIW0, EFMG517STT0, EFMG527UIW0, EFMG527UIW1, EFMG527UTT0, EFMG527UTT1, EFMG617SIW0, EFMG617STT0, EFMG627UIW0, EFMG627UIW1, EFMG627UTT0, EFMG627UTT1, EFMG628WTT00, EIED50LIW0, EIED50LIW1, EIED50LIW2, EIED55HIW0, EIED55HMB0, EIED55IKG0, EIED55IRR0, EIED5CHIW0, EIED5CHMB0, EIGD50LIW0, EIGD50LIW1, EIGD55HIW0, EIGD55HIW1, EIGD55HIW2, EIGD55HMB0, EIGD55HMB2, EIGD55IKG0, EIGD55IKG1, EIGD55IKG2, EIGD55IRR0, EIGD55IRR1, EIGD55IRR2, EIMED55IIW0, EIMED55IIW1, EIMED55IIW2, EIMED55IIW3, EIMED55IMB0
EIMED55IMB2, EIMED55IMB3, EIMED55IRR0, EIMED55QT0, EIMED5CQT0, EIMED60JIW0, EIMED60JIW2, EIMED60JIW3, EIMED60JIW4, EIMED60JIW5, EIMED60JIW6, EIMED60JMB0, EIMED60JRR0, EIMED60LSS0, EIMED60LSS2, EIMED60LSS3, EIMED60LT0, EIMED60LT2, EIMED60LT3, EIMED60LT4, EIMED6CJIW0, EIMED6CJIW2, EIMED6CJIW3, EIMED6CJIW4, EIMED6CJMB0, EIMED6CJRR0, EIMED6CLSS0, EIMED6CLSS2, EIMED6CLSS3, EIMED6CLSS4, EIMED6CLT0, EIMED6CLT2, EIMED6CLT3, EIMED6CLT4, EIMGD55IIW2, EIMGD55IIW4, EIMGD55IIW5, EIMGD55IMB2, EIMGD55IMB4, EIMGD55IMB5, EIMGD55IRR2, EIMGD55QT0, EIMGD60JIW0, EIMGD60JIW2, EIMGD60JIW3, EIMGD60JMB0, EIMGD60JRR0, EIMGD60LSS0, EIMGD60LSS2, EIMGD60LSS3, EIMGD60LT0, EIMGD60LT2, EIMGD60LT3, ELFE7337AW0, ELFE733CAW0, ELFE7437AW0, ELFE743CAW0, ELFE7537AT0, ELFE7537AW0, ELFE753CAT0, ELFE753CAW0, ELFE7637AT0, ELFE7637AW0, ELFE7637BT0, ELECTRIC, ELFE7637BW0, ELECTRIC, ELFE763CAT0, ELFE763CAW0, ELFE763CBT0, ELECTRIC, ELFE763CBW0, ELECTRIC, ELFG7337AW0, ELFG7437AW0, ELFG7537AT0, ELFG7537AW0, ELFG7637AT0, ELFG7637AW0, ELFG7637BT0, GAS, ELFG7637BW0, GAS, FAQE7001LB0, FAQE7001LW0, FAQE7001LW1, FAQE7011KB0, FAQE7011KR0, FAQE7011KW0, FAQE7011LB0, FAQE7011LW0, FAQE7017KA0, FAQE7017KB0, FAQE7017KN0, FAQE7017KR0, FAQE7017KW0, FAQE7021LB0, FAQE7021LW0, FAQE7072LA0, FAQE7072LN0, FAQE7072LR0, FAQE7072LW0, FAQE7073KA0, FAQE7073KB0, FAQE7073KN0, FAQE7073KR0, FAQE7073KW0, FAQE7077KA0, FAQE7077KB0, FAQE7077KN0, FAQE7077KR0, FAQE7077KW0, FAQE7111LW0, ELECTRIC, DRYER, FAQE7111LW1, FAQG7001LB0, FAQG7001LW0, FAQG7001LW1, FAQG7011KB0, FAQG7011KR0, FAQG7011KW0, FAQG7011LB0, FAQG7011LW0, FAQG7017KA0, FAQG7017KB0, FAQG7017KN0, FAQG7017KR0, FAQG7017KW0, FAQG7021LB0, FAQG7021LW0, FAQG7072LA0, FAQG7072LN0, FAQG7072LR0, FAQG7072LW0, FAQG7073KA0, FAQG7073KB0, FAQG7073KN0, FAQG7073KR0, FAQG7073KW0, FAQG7077KA0, FAQG7077KB0, FAQG7077KN0, FAQG7077KR0, FAQG7077KW0, FAQG7111LW0, FAQG7111LW1, FARE1011MW0, FARE1011MW1, FARE4044MW0, FARE4044MW1, FARG1011MW0, FARG1011MW1, FARG1011MW2, FARG4044MW0, FARG4044MW1, FASE7021NW0, FASE7021NW2, FASE7021NW3, FASE7073LA0, FASE7073LN0, FASE7073LR0, FASE7073LW0, FASE7073NA0, FASE7073NA2, FASE7073NA3, FASE7073NR0, FASE7073NR2, FASE7073NR3, FASE7073NW0, FASE7073NW2, FASE7073NW3, FASE7074LA0, FASE7074LN0, FASE7074LR0, FASE7074LW0, FASE7074NA0, FASE7074NA2, FASE7074NA3, FASE7074NR0, FASE7074NR2, FASE7074NR3, FASE7074NW0, FASE7074NW2, FASE7074NW3, FASG7021NW0, FASG7021NW2, FASG7021NW3, FASG7073LA0, FASG7073LN0, FASG7073LR0, FASG7073LW0, FASG7073NA0, FASG7073NA2, FASG7073NA3, FASG7073NR0, FASG7073NR2, FASG7073NR3, FASG7073NW0, FASG7073NW2, FASG7073NW3, FASG7074LA0, FASG7074LN0, FASG7074LR0, FASG7074LW0, FASG7074NA0, FASG7074NA2, FASG7074NA4, FASG7074NA5, FASG7074NR0, FASG7074NR2, FASG7074NR3, FASG7074NW0, FASG7074NW2, FASG7074NW3, FFQE5000QW0, FFQE5000QW1, FFQE5100PW0, FFQE5100PW1, FFQG5000QW0, FFQG5000QW1, FFQG5000QW2, FFQG5000QW3, FFQG5100PW0, FFRE1001PW0, FFRG1001PW0, FFRG1001PW1, FFSE5115PA0, FFSE5115PA1, FFSE5115PW0, FFSE5115PW1, FFSE5115PW2, FFSE5115PW3, FFSG5115PA0, FFSG5115PA1, FFSG5115PW0, FFSG5115PW1, FRQE7000LW0, FRQG7000LW0, GCEQ2170KE0, GCEQ2170KS0, GLEQ2170KE0, GLEQ2170KS0, GLGQ2170KE0, GLGQ2170KS0, LAQE6000LW0, LAQE7000LW0, LAQE7011KB0, LAQE7011KW0, LAQE7077KR0, LAQE7077KW0, LAQE8000LW0, LAQG6000LW0, LAQG7000LW0, LAQG7011KB0, LAQG7011KW0, LAQG7077KR0, LAQG7077KW0, LAQG8000LW0, SAGQ7070KS0, SGQ2170KS0

Frigidaire, Electrolux, White Westinghouse, Kelvinator, Gibson, Kenmore, Sears, Tappan

Not sure about your model number? Call 1-877-899-7278 and we’ll help you confirm. All brand names are the property of their respective owners and are used for compatibility reference only.
