Drum Support Roller, Drum Roller Assembly, Support Roller Wheel, Drum Roller and Axle, Drum Support Wheel, Drum Bearing Roller

7134715900, 134715900, 5304523152, 5304523155, AP6977189, PS12416849, EAP12416849

Frigidaire, Electrolux, White Westinghouse, Kelvinator, Gibson, Kenmore, Sears, Tappan

FrigidaireFFFS5115PA, FFFS5115PA0, FFFS5115PA1, FFFS5115PA2, FFFS5115PW, FFFS5115PW0, FFFS5115PW1, FFFS5115PW2, FFTW4120SW, FFTW4120SW0, FFTW4120SW1, FFTW4120SW2, FFTW4120SB, FFTW4120SB0, FFTW4120SB1, FFTW4120SB2, FAQE7077KR, FAQE7077KR0, FAQE7077KR1, FAQE7077KR2

ElectroluxEFLS627UTT, EFLS627UTT0, EFLS627UTT1, EFLS627UTT2, EFLS617STT, EFLS617STT0, EFLS617STT1, EFLS617STT2, EFLS527UIW, EFLS527UIW0, EFLS527UIW1, EFLS527UIW2, EFLS517SIW, EFLS517SIW0, EFLS517SIW1, EFLS517SIW2, EIED55HIW, EIED55HIW0, EIED55HIW1, EIED55HIW2

White WestinghouseWFWS4200HW, WFWS4200HW0, WFWS4200HW1, WFWS4200HW2, WFWS4200HS, WFWS4200HS0, WFWS4200HS1, WFWS4200HS2

KelvinatorKFWS4200HW, KFWS4200HW0, KFWS4200HW1, KFWS4200HW2, KFWS4200HS, KFWS4200HS0, KFWS4200HS1, KFWS4200HS2

GibsonGFWS4200HW, GFWS4200HW0, GFWS4200HW1, GFWS4200HW2, GFWS4200HS, GFWS4200HS0, GFWS4200HS1, GFWS4200HS2

Kenmore110.66812600, 110.66812601, 110.66812602, 110.66812603, 110.66822600, 110.66822601, 110.66822602, 110.66822603, 110.66832600, 110.66832601, 110.66832602, 110.66832603, 110.67812600, 110.67812601, 110.67812602, 110.67812603

Sears110.66812600, 110.66812601, 110.66812602, 110.66812603, 110.66822600, 110.66822601, 110.66822602, 110.66822603, 110.66832600, 110.66832601, 110.66832602, 110.66832603, 110.67812600, 110.67812601, 110.67812602, 110.67812603

TappanTFTW4120SW, TFTW4120SW0, TFTW4120SW1, TFTW4120SW2, TFTW4120SB, TFTW4120SB0, TFTW4120SB1, TFTW4120SB2

Professional Repair Time: 60-90 minutes
DIY Repair Time: 90-120 minutes
Difficulty Rating: Moderate-Advanced (3/5) — Requires basic mechanical skills, careful drum handling (heavy), drive belt removal and reinstallation, drum roller removal and installation, attention to detail, understanding of drum support system

1. Unplug the dryer from the electrical outlet to ensure complete power disconnection, or turn off power at the circuit breaker if the dryer is hardwired.
2. Verify power is off by attempting to turn on the dryer. The dryer should not respond and the display should be blank.
3. Pull the dryer away from the wall to provide access to the rear panel and working space around the dryer.
4. Take multiple photos of the drum roller locations, mounting positions, axle shaft orientation, and how the rollers contact the drum before disassembly. Document from multiple angles. This is absolutely critical for proper reassembly. Use a camera or smartphone to capture high-quality images.
5. Remove the dryer front panel or access panel by removing the mounting screws (typically 4-6 screws along the bottom or sides of the front panel). Set the screws aside in a safe location.
6. Carefully lift or slide the front panel away from the dryer frame to expose the interior components and drum rollers.
7. Locate the drive belt that runs around the drum. Note how the belt is routed around the drum, motor pulley, and idler pulley.
8. Take additional detailed photos of the drive belt routing before removing the belt. This is critical for proper belt reinstallation.
9. Release the belt tension by pushing the idler pulley toward the motor to create slack in the belt.
10. Remove the drive belt from the motor pulley and idler pulley, then lift the belt off the drum.
11. Carefully lift the front edge of the drum and tilt it forward to disengage the drum from the drum rollers at the rear.
12. Support the drum with one hand or have a helper hold the drum while you work on the rollers. Important: The drum is heavy (15-25 pounds). Use caution to avoid dropping it.
13. Locate the drum rollers mounted on the dryer frame at the rear of the drum cavity (typically two rollers, left and right sides).
14. Take additional detailed photos of the drum roller mounting, axle shaft position, and how the roller wheel contacts the drum before removal.
15. Remove the drum roller mounting hardware (typically a tri-wing screw, Phillips screw, or clip) that secures the axle shaft to the dryer frame.
16. Carefully remove the old drum roller and axle shaft from the dryer frame and place it on a clean work surface with adequate space for inspection.
17. Repeat the removal process for the second drum roller on the opposite side of the dryer.
18. Inspect the old drum rollers for visible damage such as worn, flattened, or cracked roller wheels, failed or rough bearings, bent axle shafts, or debris accumulation. This confirms the diagnosis.
19. Inspect the drum rim where the rollers contact the drum for wear, damage, or debris. Clean the drum rim if necessary using a dry cloth.
20. Inspect the drum roller mounting locations on the dryer frame for damage, corrosion, or debris. Clean the mounting areas if necessary using a dry cloth.
21. Unpack the new 5304523155 drum roller assemblies from their packaging. Handle carefully to avoid damaging the roller wheels or bearings. Note: You should have two drum roller assemblies for complete replacement.
22. Verify the drum roller specifications match the old rollers: roller wheel diameter approximately 2-3 inches, roller wheel width approximately 1-2 inches, axle shaft length approximately 3-4 inches, bearing type (ball bearings or bushings), mounting hardware type.
23. Compare the new drum rollers to the old ones to verify the dimensions, roller wheel size, axle shaft length, bearing type, mounting hardware, and overall appearance match. Ensure you have the correct replacement parts.
24. Inspect the new drum rollers for any damage or defects before installation. The roller wheels should be smooth and round with no flat spots, cracks, or damage. The bearings should spin freely and smoothly. The axle shafts should be straight with no bends or damage.
25. Test the new drum roller bearings by spinning the roller wheel on the axle shaft. The wheel should spin freely and smoothly without binding, sticking, or rough spots.
26. Position the first new drum roller and axle shaft on the dryer frame, aligning the axle shaft with the mounting hole and orienting the roller wheel to contact the drum rim.
27. Install the drum roller mounting hardware (tri-wing screw, Phillips screw, or clip) to secure the axle shaft to the dryer frame. Tighten firmly but do not overtighten, which can damage the mounting hole or axle shaft.
28. Verify the drum roller is securely mounted and does not wobble or shift when gently pressed.
29. Verify the roller wheel spins freely on the axle shaft by manually rotating the wheel. The wheel should spin smoothly without binding or resistance.
30. Repeat the installation process for the second drum roller on the opposite side of the dryer.
31. Verify both drum rollers are at the same height and properly aligned to provide even drum support.
32. Carefully lower the drum back into position, ensuring the drum rim rests on both drum roller wheels.
33. Verify the drum is properly seated on the drum rollers by gently rocking the drum. The drum should rest evenly on both rollers without tilting or wobbling.
34. Reinstall the drive belt by wrapping it around the drum, routing it under the idler pulley, and placing it on the motor pulley. Use your detailed photos to ensure correct belt routing.
35. Verify the drive belt is properly seated on the drum, idler pulley, and motor pulley by visually inspecting the belt path.
36. Manually rotate the drum by hand to verify smooth rotation. The drum should rotate freely and smoothly without binding, sticking, or rough spots.
37. Listen for unusual sounds while manually rotating the drum. The drum should rotate quietly without squealing, grinding, or other unusual sounds.
38. Verify the drum rollers are rotating properly by watching the roller wheels as you manually rotate the drum. The roller wheels should spin freely as the drum rotates.
39. Reinstall the dryer front panel by carefully positioning it on the dryer frame and securing it with the mounting screws.
40. Verify the front panel is fully seated and aligned with the dryer frame.
41. Push the dryer back into position against the wall.
42. Restore power by plugging in the dryer or turning on the circuit breaker.
43. Turn on the dryer and set it to a drying cycle.
44. Verify the dryer drum rotates smoothly and consistently throughout the cycle. The drum should rotate at a steady speed without hesitation or irregular movement.
45. Listen for unusual noises from the dryer interior. The dryer should operate quietly without squealing, squeaking, grinding, or other unusual sounds.
46. Allow the dryer to complete the full drying cycle without interruption.
47. Verify the clothes are dry at the end of the cycle, confirming proper drum rotation and heating operation.
48. Run multiple drying cycles to verify the drum rollers operate properly under normal conditions without issues.
49. Monitor the dryer for 24-48 hours to ensure the drum rollers operate properly without issues.

Safety Notes: Always unplug the dryer before working on it to prevent electrical shock. The drum is heavy (15-25 pounds)—use caution when lifting and supporting it to avoid dropping or damaging it. Always replace drum rollers in pairs (left and right sides) to ensure even drum support and smooth operation. Verify the drum is properly seated on the drum rollers before reinstalling the drive belt. This repair requires moderately advanced mechanical skills and careful attention to detail—most homeowners can complete this repair successfully with proper precautions and documentation.

1. Always replace drum rollers in pairs (left and right sides) even if only one roller appears damaged. Mismatched rollers with different wear levels will cause the drum to tilt or wobble, leading to poor drying performance, excessive noise, and premature failure of the new roller. Replacing both rollers ensures even drum support and smooth, quiet operation.
2. Test the new drum roller bearings before installation by spinning the roller wheel on the axle shaft. The wheel should spin freely and smoothly for at least 10-15 seconds without binding, sticking, or rough spots. A stiff or rough-spinning roller indicates a defective bearing that should be replaced before installation.
3. Document the drive belt routing with detailed photos before removing the belt. Take high-quality photos of the belt path around the drum, motor pulley, and idler pulley from multiple angles. This documentation is critical for ensuring correct belt reinstallation and preventing belt misalignment, which can cause poor drum rotation and premature belt wear.
4. Verify the drum is properly seated on both drum rollers before reinstalling the drive belt. The drum should rest evenly on both rollers without tilting or wobbling to one side. If the drum tilts, verify both rollers are at the same height and properly aligned. Improper drum seating will cause the drum to wobble during operation and produce thumping sounds.
5. Inspect the drum rim where the rollers contact the drum for wear or damage. A worn or damaged drum rim will prevent proper roller contact and cause the drum to wobble even with new rollers installed. If the drum rim is severely worn or damaged, the drum may need replacement along with the rollers.
6. Clean the drum roller mounting areas on the dryer frame before installing new rollers. Remove any lint, dust, or debris from the mounting locations using a dry cloth. Debris can prevent proper roller seating and cause the rollers to shift during operation.
7. Verify the roller wheels spin freely and smoothly after installation. Manually rotate each roller wheel to confirm smooth operation. A stiff or rough-spinning roller indicates improper installation or a defective bearing. Stop and verify the installation before running the dryer.
8. The drum roller bearings are precision components that require careful handling. Avoid dropping the rollers or applying excessive force during installation. Rough handling can damage the bearings and cause premature failure even before the dryer is used.
9. Listen carefully for squealing or squeaking sounds during the first few cycles after installation. New drum rollers sometimes produce minor squeaking during the first few cycles as the bearings break in. This should diminish after a few cycles. If squeaking persists or increases, stop the dryer and verify the rollers are properly installed and spinning freely.
10. The drum rollers are high-wear components that typically fail after 5-10 years of regular use. With average use (3-4 loads per week), the drum rollers typically last 7-10 years before failure. Replace the drum rollers promptly when failure is detected to prevent drum damage and to restore reliable, quiet dryer operation. This repair is cost-effective compared to dryer replacement—the cost of drum roller replacement ($60-120 for a pair) is far less than the cost of a new dryer ($600-2,000+).

• Loud squealing, squeaking, or grinding sounds from dryer during operation
• Dryer drum not rotating smoothly or hesitating during rotation
• Dryer drum wobbling or tilting during operation
• Visible wear or flat spots on roller wheels
• Dryer drum feeling rough or catching when manually rotated
• Dryer taking longer than normal to dry clothes (due to inefficient drum rotation)
• Dryer making thumping sounds during operation
• Drum rollers not spinning freely
• Bearings worn or failed
• Roller wheels cracked or broken
• Axle shaft worn or bent
• Drum not supported properly
