Refrigerator Door Not Sealing? Door Gasket 241778315 – Fix Fresh-Food Seal Failure Fast
If your Electrolux or Frigidaire French-door refrigerator is losing cold air, running constantly, or showing frost buildup around the fresh-food door, a failed door gasket is the most common cause. In most Electrolux and Frigidaire 36-inch French-door refrigerators, the magnetic fresh-food door gasket hardens, tears, or loses its seal over time. When it fails, warm air infiltrates the fresh-food compartment, causing temperature instability, compressor overrun, and condensation or frost at the door perimeter. ⚡ Common failure point in Electrolux and Frigidaire-built French-door refrigerators. Part 241778315 is the genuine OEM replacement gasket (approximately 39 × 17 inches) that restores a full magnetic seal and returns the refrigerator to normal operating efficiency.
❓ Is This the Right Part?
This is the correct fix if ALL of the following are true:
- ✔ QUALIFIER 1 — refrigerator powers on and compressor runs normally
- ✔ QUALIFIER 2 — freezer compartment maintains temperature correctly
- ✔ QUALIFIER 3 — door hinges and closure mechanism are intact
- ✔ ONLY problem is fresh-food door not sealing, warm air infiltration, or visible gasket damage
Not sure? Send us your model number — we'll confirm before you order.
🔧 Common Symptoms
- Fresh-food compartment warmer than set temperature
- Condensation or frost forming around the fresh-food door frame
- Compressor running continuously or cycling more frequently than normal
- Visible tears, cracks, hardening, or gaps in the door gasket
✔ If these symptoms match, a failed door gasket is the most likely cause.
✔ In most cases, replacing the door gasket restores a full airtight seal and normal refrigerator operation immediately.
📦 Part Details
- Part Number: 241778315
- Type: Magnetic fresh-food refrigerator door gasket — 36-inch French-door, approximately 39 × 17 inches, supplied in light gray
- Replaces: 241778301, 241778303, 241778307, 241778308, 7241778301, 7241778303
- Brands: Electrolux, Frigidaire, Kenmore (253-series), Crosley, White-Westinghouse
Inspect the door hinges and door alignment while the gasket is removed — a misaligned door will cause a new gasket to fail prematurely. If the door sags or does not close squarely, adjust the hinge before installing the replacement gasket.
⚙️ Installation
Skill Level: EASY — 20–30 minutes. Disconnect power before servicing. Peel the old gasket from the door liner starting at a corner, clean the channel thoroughly, then press the new gasket into the channel working around the perimeter. Allow the gasket to warm to room temperature before installation for easier seating.
✓ Compatible Models
Confirmed compatible with 25370312213, 25370313212, 25370313214, 2537034241J, 25370343210, 25370343410, 25370343411, 25370343412, 25370343413, 25370343416, 25370343419, 2537034341A, 2537034341H, CFD26SDS0, CFD26WIS0 plus additional Electrolux, Frigidaire, and Kenmore 253-series models. Contact us to verify your model number before ordering.
💡 Pro Tip
The original 241778307 gasket was supplied in dark gray. The current OEM replacement 241778315 is supplied in a lighter gray colour. This is a normal supersession change — the fit, function, and magnetic seal are identical. If colour matching is critical, confirm with us before ordering.
✓ Model-Specific Repair Pages
✅Compatibility & Cross Reference
Not sure about your model number? Call 1-877-899-7278 and we’ll help you confirm. All brand names are the property of their respective owners and are used for compatibility reference only.
