Samsung Range / Cooktop Assembly Module Spark DG96-00297A, Replaces DG96-00221A

Genuine Samsung spark module assembly (DG96-00297A), identified by Samsung parts distributor Encompass as “ASSEMBLY MODULE SPARK” and specified for NX583G0VBSR, AC110/240V. It is documented for compatible Samsung ranges and gas cooktops.

Is This the Right Part?

Common Symptoms

• Multiple surface burners fail to ignite despite gas being available.
• Burners spark intermittently or weakly.
• Burners click repeatedly without lighting.
• Some burners spark while others do not, when the module or its output circuit is defective.

Check Before Replacing

• With the appliance unplugged and the gas supply shut off, visually inspect the spark-module wiring, connectors, and electrode wires for loose connections, burn marks, or visible damage.
• Compare the visible spark behavior at the affected and unaffected burners, if testing can be performed safely and without exposure to escaping gas.
• Before condemning the module, inspect the affected burner electrode and spark wire because either may cause weak or absent sparking.
• If electrical testing is performed, follow the appliance’s service documentation and use appropriate electrical-safety procedures; do not work on energized wiring unless qualified.

Pro Tip

Part Details

Key Features

• Genuine Samsung range spark-module assembly.
• Supplies ignition power to surface-burner spark electrodes.
• Used on compatible Samsung gas ranges and cooktops.
• Archived documentation specifies AC110/240V application for the identified assembly.
• Prior documented predecessor number: DG96-00221A.

Installation Notes

• Disconnect appliance power before service and shut off the gas supply before accessing ignition components.
• Access the module only according to the appliance’s model-specific service documentation.
• Transfer wiring one connection at a time or photograph the original connections before disassembly; do not guess wire locations.
• Securely reconnect all original wiring and verify that wires are routed away from hot surfaces and moving parts.
• After reassembly, restore gas and power only after confirming that panels and connections are properly installed; stop immediately if a gas odor is detected.

Verified Compatible Models

FX510BGS/XAA, FX710BGS/XAA, FX710BGS/XAC, NA30K6550TG/AA, NA30K6550TS/AA, NA30K7750TG/AA, NA30K7750TS/AA, NA30M9750TS/AA, NA36K6550TG/AA, NA36K6550TS/AA, NA36K7750TG/AA, NA36K7750TS/AA, NA36M9750TS/AA, NX58F5300SS/AA, NX58F5500SB/AA, NX58F5500SS/AA, NX58F5500SW/AA, NX58F5700WS/AA, NX58H5600SS/AA, NX58H5600SS/AC, NX58H5650WS/AA, NX58H9500WS/AA, NX58H9500WS/AC, NX58H9950WS/AA, NX58J5600SG/AA, NX58J7750SS/AA, NX58J7750SS/AC, NX58K3310SB/AA, NX58K3310SS/AA, NX58K3310SW/AA, NX58K7850SG/AA, NX58K7850SS/AA, NX58K9500WG/AA, NX58K9500WG/AC, NX58K9850SG/AA, NX58K9850SS/AA, NX58M5600SB/AA, NX58M5600SW/AA, NX58M6630SG/AA, NX58M6630SS/AA, NX58M6650WG/AA, NX58M6650WS/AA, NX58M6850SG/AA, NX58M6850SS/AA, NX58M9420SS/AA, NX583G0VBBB/AA, NX583G0VBBBAA, NX583G0VBWW/AA, NY58J9850WS/AA, NY58J9850WS/AC

Fitment reminder: Match the complete appliance model number, including suffix or revision where applicable, before ordering.
