Whirlpool Refrigerator LED Module Service Kit, Chrome W11683244
Genuine Whirlpool OEM refrigerator LED module service kit with 9+3 LED modules and chrome bezels. The updated kit requires replacement of all original single-point LED assemblies in the appliance.
Refrigerator W11683244
Is This the Right Part?
Confirm the complete appliance model number before ordering.
✅ Cross Reference Information
Part Details
Verified Compatible Models
KRFF507EBL00, KRFF507EBL01, KRFF507ESS00, KRFF507ESS01, KRFF507EWH00, KRFF507EWH01, KRFF507HBL00, KRFF507HBS00, KRFF507HPS00, KRFF507HPS01, KRFF507HWH00, KRFF707EBS00, KRFF707ESS01, KRMF606ESS00, KRMF606ESS01
Model Families: KRFF507E, KRFF507H, KRFF707E, KRMF606ESS, KRMF706E
Fitment reminder: Match the complete model number including suffix and revision before ordering.
Installation Notes
- Disconnect power and shut off water or gas where applicable.
- Photograph wiring, hoses, clamps, and mounting positions.
- Compare the new part with the original before installation.
- Inspect nearby wires, hoses, seals, and connectors for damage.
- Test the appliance and check for leaks, unusual sounds, or error codes.
Use a qualified technician when diagnosis or installation is outside your experience. Gas parts should be installed by a licensed technician.
Part number W11683244 replaces W10739303, W10843828, W11205082
Supported Models:
✓ Model-Specific Repair Pages
✅Compatibility & Cross Reference
Not sure about your model number? Call 1-877-899-7278 and we’ll help you confirm. All brand names are the property of their respective owners and are used for compatibility reference only.
