Refrigerator Warm or Freezer Frosting Over? Evaporator Fan Motor WG03F08474 – Fix No-Airflow Fast
When a GE refrigerator stops cooling properly, develops heavy frost on the freezer back wall, or makes a loud grinding or buzzing noise, a failed evaporator fan motor is almost always the cause. In GE, Café, Profile, and Monogram refrigerators, the evaporator fan motor circulates cold air through both the freezer and fresh food compartments — when it fails, airflow stops, food warms up, and frost accumulates on the evaporator coils. ⚡ Common failure point in GE French door and side-by-side refrigerators. Part WG03F08474 is the genuine OEM replacement that directly supersedes WR60X35205, WG03F06743, and WG03F07207 — restoring full airflow and cooling with no modification required.
❓ Is This the Right Part?
This is the correct fix if ALL of the following are true:
- ✔ Your refrigerator has power and the compressor is running
- ✔ The defrost heater and defrost thermostat have been tested and confirmed OK
- ✔ The evaporator coils are frosted over or the fan blade is not spinning
- ✔ You hear grinding, buzzing, or squealing from inside the freezer compartment
- ✔ ONLY problem is insufficient cooling, frost buildup, or loud fan noise
Not sure? Send us your model number — we'll confirm before you order.
🔧 Common Symptoms
- Refrigerator not cooling or warmer than set temperature
- Freezer section cooling but fresh food compartment is warm
- Loud humming, grinding, squealing, or buzzing from inside the freezer
- Noise stops when freezer door is opened (fan shuts off on door open)
- Excessive frost or ice buildup on the back wall of the freezer
- Fan blade visible but not spinning when freezer door switch is pressed
- Refrigerator runs constantly but never reaches set temperature
- Ice maker stops producing ice due to insufficient airflow
✔ If these symptoms match, the evaporator fan motor is the most likely failed component in the system.
✔ In most cases, replacing the fan motor with WG03F08474 restores full airflow and cooling immediately.
📦 Part Details
- Part Number: WG03F08474
- Type: Genuine OEM GE Refrigerator Evaporator Fan Motor
- Replaces: WR60X35205, WG03F06743, WG03F07207, 197D9873P005, WR60X20880, WR60X24723, WR60X26281, WR60X29099, WR60X35665 — no modification required
- Brands: GE, Café, Profile, Monogram
⚙️ Installation Notes
Skill Level: INTERMEDIATE — Allow 45–60 minutes. Unplug the refrigerator before beginning any work. Access the evaporator fan by removing the freezer rear panel — allow any frost on the evaporator coils to thaw completely before reassembling (a hair dryer on low speeds this up). Disconnect the wire harness, remove the mounting bracket screws, and swap the motor. Confirm the fan blade spins freely by hand after installation. Restore power and press the freezer door switch to verify the fan runs before closing up.
💡 Pro Tip
If the evaporator coils were heavily frosted when you found the failed motor, the defrost heater or defrost thermostat may also be failing — a blocked defrost cycle is often what caused the frost buildup that killed the motor in the first place. While the rear panel is off, inspect the defrost heater for breaks and test the defrost thermostat for continuity. Replacing a failed defrost component at the same time prevents the new motor from failing again within months.
CFE28TP4MLW2, CFE28TP4MJW2, CFE28TP4MFW2, CFE28TP3MJD1, CFE28TP3MID1, CFE28TP2MHS1
✓ Model-Specific Repair Pages
✅Compatibility & Cross Reference
Not sure about your model number? Call 1-877-899-7278 and we’ll help you confirm. All brand names are the property of their respective owners and are used for compatibility reference only.
