SQUEALING OR SQUEAKING DURING TUMBLING
Frigidaire Dryer Idler Pulley Assembly 131863007, Replaces 131863004, 131863000, 131826900, 131434600, 131580400, Fixes Squealing or squeaking during tumbling
Genuine OEM dryer idler pulley and arm assembly that maintains tension and alignment on the drum drive belt.
Part 131863007Replaces 131863004, 131863000, 131826900, 131434600, 131580400Frigidaire
Genuine OEM dryer idler pulley and arm assembly that maintains tension and alignment on the drum drive belt.
Is This the Right Part?
Part Number131863007
Replaces131863004, 131863000, 131826900, 131434600, 131580400
ManufacturerFrigidaire
Appliance TypeDryer
Part TypeDryer Idler Pulley Assembly
✅ Cross Reference Information
Current Part Number131863007
Replaces131863004, 131863000, 131826900, 131434600, 131580400
Common Symptoms
- Noisy operation, including squealing or squeaking
- Drum stops turning while the motor may continue running
- Drum does not tumble or tumbles inconsistently
- Drive belt appears loose, slips, or comes off
- Vibration or thumping associated with a worn or binding pulley
Check Before Replacing
- Unplug the dryer before inspection.
- With the dryer disconnected from power and access provided according to the model service procedure, inspect the idler pulley for cracks, heavy wear, or damage.
- Verify that the pulley rotates freely without binding when checked by hand.
- Inspect the drive belt for looseness, fraying, glazing, or evidence of slipping.
- Confirm that the belt is routed correctly around the motor pulley and idler pulley and remains aligned during manual drum rotation.
Pro Tip
Inspect the drive belt whenever the idler assembly is accessible because a worn or binding pulley can contribute to abnormal belt wear.
Part Details
Part Number131863007
Part TypeDryer Idler Pulley Assembly
ManufacturerFrigidaire
Appliance TypeDryer
Primary FunctionMaintains tension and alignment on the dryer drum drive belt so the drum can rotate properly.
Cross References131863004, 131863000, 131826900, 131434600, 131580400
Key Features
- Genuine Frigidaire OEM idler pulley assembly
- Includes the idler arm and pulley
- Spring-loaded design maintains drive-belt tension
- Supports belt alignment during drum rotation
- Used on compatible Frigidaire and related Electrolux-family dryers
Installation Notes
- Disconnect electrical power before beginning service.
- Use the model-specific access procedure because panel removal can vary by dryer design.
- Note or photograph the existing belt-routing path before removing the belt.
- Release belt tension before removing the idler assembly, then reinstall the belt with the idler and motor pulley correctly aligned.
- After installation, manually check belt tracking and pulley movement before restoring power.
Verified Compatible Models
AEQ6000CES0, AEQ6000CES1, AEQ6000CES2, AEQ6000ES0, AEQ6000ES1, AEQ6000ES2, AEQ6400HE0, AEQ6400HS0, AEQ6500CFG0, AEQ6500CFS0, AEQ6700CFE0, AEQ6700CFS0, AEQ6700FE0, AEQ6700FS0, AEQ7000CEG0
Fitment reminder: Match the complete appliance model number, including suffix or revision where applicable, before ordering.
