Whirlpool Corporation Refrigerator compressor kit W10823815, Replaces R0660026, 68001140, 2258449, 2196771, 2218965

Genuine Whirlpool compressor kit for refrigerator sealed systems. The kit includes the relay, overload, start capacitor, and drier. Installation requires sealed-system refrigerant recovery and recharging by a qualified technician.

Is This the Right Part?

✅ Cross Reference Information

Common Symptoms

• Freezer or refrigerator fails to cool
• Compressor hums or clicks but does not start
• Compressor repeatedly starts and shuts off on overload
• Refrigerator runs continuously but cooling remains inadequate
• Cooling is intermittent when the compressor or sealed system is impaired

Check Before Replacing

• Unplug the appliance and allow the compressor and starting components to cool before inspection.
• Confirm that the appliance has power and that the compressor is receiving the proper operating command; absence of power points to an upstream control or wiring issue rather than this kit.
• Listen for compressor humming, clicking, or repeated overload cycling, while avoiding contact with energized components.
• A qualified technician may check continuity between the compressor terminals with power disconnected; an open winding can indicate a defective compressor, but this check alone does not establish a complete diagnosis.
• Have a qualified sealed-system technician evaluate refrigerant pressures, frost pattern, leaks, and compressor pumping performance before condemning the compressor.

Pro Tip

Part Details

Key Features

• Genuine Whirlpool OEM refrigerator compressor kit
• Includes relay, overload, start capacitor, and drier
• Used in refrigerator, freezer, and some ice-maker applications listed by the parts supplier
• Sealed-system component requiring specialized recovery, evacuation, and refrigerant-charging equipment

Installation Notes

• Installation involves opening the sealed refrigeration system and must be performed by a trained, qualified technician.
• The supplied relay, overload, start capacitor, and drier are part of the kit and should be handled according to the applicable Whirlpool service information for the appliance.
• Refrigerant must be recovered and the sealed system properly evacuated, repaired, and recharged; do not vent refrigerant or attempt ordinary DIY replacement.
• Confirm the exact appliance model and refrigerant/service requirements before installation, because compressor service procedures and starting components can vary by model.

Verified Compatible Models

10639420990, 10639422990, 10639424990, 10639427990, 10639430990, 10639432990, 10639434990, 10639437990, 10660832100, 10660832101, 10660832102, 10660834100, 10660834101, 10660834102, 10660842100, CSW45A1D, CSW45PA1B0, CSW45PA1D, ED050FXGW03, EH101FXRQ01, EH105FXRQ00, EH105FXRQ01, GI1500PHB3, GI1500PHB4, GI1500PHB5, GI1500PHB6, GI1500PHB7, GI1500PHB8, GI1500PHW3, GI1500PHW4, GI1500PHW5, GI1500PHW6, GI1500PHW7, GI1500PHW8, GI1500XHB3, GI1500XHB4, GI1500XHB5, GI1500XHB6, GI1500XHB7, GI1500XHB8, GI1500XHB9, GI1500XHN3, GI1500XHN4, GI1500XHS3, GI1500XHS4, GI1500XHS5, GI1500XHS6, GI1500XHS7, GI1500XHS8, GI1500XHS9, GI1500XHT3, GI1500XHT4, GI1500XHT5, GI1500XHT6, GI1500XHT7, GI1500XHT8, GI1500XHT9, GI1500XHW3, GI1500XHW4, GI1500XHW5, GI1500XHW6, GI1500XHW7, GI1500XHW8, GI1500XHW9, GI15NDXTB0, GI15NDXTQ0, GI15NDXTS0, GI15NDXXB2, GI15NDXXQ2, GI15NDXXS2, GI15NDXZB1, GI15NDXZB2, GI15NDXZQ1, GI15NDXZQ2, GI15NDXZS1, GI15NDXZS2, GI15NFLTB0, GI15NFLTS0, GI15NFRTB0, GI15NFRTS0, GI15PDXZS0, GI15PDXZS1, JEACS50SL4, JEACS50SL6, JEACS50SL7, JEACS50SL8, JEACS50SLF1, WUI75X15HB00, WUI75X15HW00, WUI75X15HZ00, WUI95X15HZ00, ZDI15CBBN, ZDI15CWWN, ZDIS15CSSN

Fitment reminder: Match the complete appliance model number, including suffix or revision where applicable, before ordering.
