Whirlpool Dishwasher Control Board (ACU Final Assembly) W11672039, Replaces W11648208, W11563997

Whirlpool electronic control / ACU final assembly used as the dishwasher's main control unit. Encompass identifies it as an ACU final assembly for WDTA50/750/740 2023 high-voltage applications.

Is This the Right Part?

✅ Cross Reference Information

Common Symptoms

• Displayed error codes.
• Wash cycles that do not complete.

Check Before Replacing

• Record any displayed error code and the point in the cycle where operation stops.
• Observe whether the control panel accepts selections and whether the selected cycle completes.
• Verify the dishwasher's exact model number and confirm W11672039 is listed for that model before ordering or installing the board.

Pro Tip

Part Details

Key Features

• Genuine Whirlpool dishwasher ACU final assembly.
• Electronic main control unit.
• Controls wash-cycle operation, water flow, and drying functions.
• Whirlpool lists it as replacing W11648208 and W11563997.

Installation Notes

• Disconnect electrical power at the breaker before servicing the dishwasher.
• Use the technical sheet and service information for the exact dishwasher model during diagnosis and replacement.
• Because this is an electronic control assembly, professional service is appropriate if fault-code interpretation or electrical testing is required.

Verified Compatible Models

WDT740SALB1, WDT740SALB2, WDT740SALB3, WDT740SALW1, WDT740SALW2, WDT740SALW3, WDT740SALZ1, WDT740SALZ2, WDT740SALZ3, WDT750SAKB1, WDT750SAKB2, WDT750SAKB3, WDT750SAKV1, WDT750SAKV2, WDT750SAKV3, WDT750SAKW1, WDT750SAKW2, WDT750SAKW3, WDT750SAKZ1, WDT750SAKZ2, WDT750SAKZ3, WDTA50SAKB1, WDTA50SAKB2, WDTA50SAKB3, WDTA50SAKT1, WDTA50SAKT2, WDTA50SAKT3, WDTA50SAKV1, WDTA50SAKV2, WDTA50SAKV3, WDTA50SAKW1, WDTA50SAKW2, WDTA50SAKW3, WDTA50SAKZ1, WDTA50SAKZ2, WDTA50SAKZ3

Fitment reminder: Match the complete appliance model number, including suffix or revision where applicable, before ordering.
