GE Range ASM, Burner Cap Center, Dual Oval WS01F07283, Replaces 164D9662G001MA, WB29X24971

Center dual-oval burner-cap assembly for GE gas ranges. The requested OEM number is listed in range parts diagrams as the center burner-cap assembly. Some retailers also describe it as a center or fish-shaped burner cap.

Is This the Right Part?

✅ Cross Reference Information

Common Symptoms

• Center burner fails to ignite or ignites intermittently
• Uneven, incomplete, or localized flame around the dual-oval burner
• Delayed ignition or weak heat from the center burner
• Cap rocks, sits crooked, or is visibly damaged, cracked, or heavily corroded

Check Before Replacing

• Turn the range off and allow the cooktop and burner parts to cool completely before inspection.
• Confirm that the center dual-oval cap is installed on the correct center burner head and sits flat without rocking.
• Remove and visually inspect the cap for cracks, chips, distortion, severe corrosion, or blocked openings; do not use a damaged cap.
• Verify that the cap and burner head are clean and completely dry, and that nearby burner openings are not obstructed.
• If the cap is correctly seated but ignition or flame problems remain, have the burner head, igniter, gas supply, and controls evaluated by a qualified appliance technician.

Pro Tip

Part Details

Key Features

• GE burner-cap assembly identified as ASM, Burner Cap Center, Dual Oval
• Designed for the center oval or fish-shaped burner position on compatible GE gas ranges
• Removable burner component for cleaning and replacement
• Archived replacement numbers include WB29X24971 and 164D9662G001MA

Installation Notes

• Shut off the appliance and let all burner components cool before handling.
• Lift off the existing center dual-oval cap and compare the replacement's shape and orientation with the original.
• Install the cap on the matching center dual-oval burner head, aligned so it sits flat and centered over the burner assembly.
• Ensure the cap and burner head are dry before restoring operation.
• After installation, check the burner flame for stable, even ignition; gas-related diagnosis or installation should be performed by a qualified technician.

Verified Compatible Models

P2S930SEL1SS, P2S930YP1FS, PC2B940SEJ1SS, PC2B940SEJ2SS, PC2B940SEJ3SS, PC2B940SEJ4SS, PC2B940SEJ5SS, PC2B940SEJ6SS, PC2B940SEJ7SS, PC2B940SEJ8SS, PC2S930SEL1SS, PC2S930SEL2SS, PC2S930SEL3SS, PC2S930SEL4SS, PC2S930YP1FS, IO940TS0A, IO950FS0A, IO950FS0B, IO950TS0A, PCGB940SEJ1SS, PCGB940SEJ2SS, PCGB940SEJ3SS, PCGB940ZEJ1SS, PCGB940ZEJ2SS, PCGB940ZEJ3SS, PCGB940ZEJ5SS, PCGB960FEJ2DS, PCGB980ZEJ1SS, PCGB980ZEJ2SS, PCGB980ZEJ3SS, PCGS930BEL1TS, PCGS930BEL2TS, PCGS930BEL3TS, PCGS930BEL4TS, PCGS930BP1TS, PCGS930EEL1ES, PCGS930FEL1DS, PCGS930FEL2DS, PCGS930FEL3DS, PCGS930SEL1SS, PCGS930SEL2SS, PCGS930SEL3SS, PCGS930SEL4SS, PCGS930YP1FS, PCGS960BEL1TS, PCGS960BEL2TS, PCGS960EEL1ES, PCGS960EEL2ES, PCGS960EEL3ES, PCGS960EEL4ES, PCGS960SEL1SS, PCGS960SEL2SS, PCGS960SEL3SS, PCGS960SEL4SS, PCGS960YP1FS, PGB930SEJ5SS, PGS930SEL1SS, PGS930SEL3SS, PGS930YP1FS, PGS960SEL1SS

Fitment reminder: Match the complete appliance model number, including suffix or revision where applicable, before ordering.
