LG Dishwasher Rail Assembly AHC73575010

Is This the Right Part?

✅ Cross Reference Information

Common Symptoms

• Upper rack binds, derails, or feels unusually rough during movement
• Upper rack sags or is not properly supported on the right side
• Rack movement is restricted because the rail or retaining clips are damaged

Check Before Replacing

• With the dishwasher unloaded and the door fully open, slowly move the upper rack and check whether resistance occurs specifically at the right rail.
• Visually inspect the right rail assembly, rack wheels, stops, and retaining clips for cracks, looseness, or displacement.
• Compare the right-side rail and rack-wheel engagement with the opposite side; do not force the rack if it binds.
• Confirm that the rack is seated in the rail and that no dish or utensil is obstructing the rail path.

Pro Tip

Part Details

Installation Notes

• Remove the upper rack according to the dishwasher’s model-specific owner or service instructions before accessing the rail assembly.
• Keep the rack unloaded while checking rail alignment and movement.
• After installation, verify that the rack is fully seated in the rail and moves smoothly without binding before loading dishes.
• Do not force the rack or operate the dishwasher if the rail, rack, or retaining components are visibly damaged.

Verified Compatible Models

LDP6797ST, LDP6797WW, LDP7808BD, LDP7808SS, LDPH7972D, LDPH7972S, LDPM6762S, LDPS6762D, LDPS6762S, LDT7797ST, LDT7808BM, LDT7808ST, LDTH7972D, LDTH7972S, LSDT9908BD

Fitment reminder: Match the complete appliance model number, including suffix or revision where applicable, before ordering.
