Whirlpool Dishwasher lower door seal W10909089

Whirlpool OEM lower dishwasher door seal, also identified as a door-bottom seal.

Is This the Right Part?

Common Symptoms

• Water seepage or leakage at the bottom of the dishwasher door during wash or rinse cycles.

Check Before Replacing

• Inspect the lower door seal for visible cracking, deformation, tearing, or separation.
• Observe whether water is escaping specifically from the lower door area during operation; confirm the leak source before replacing the seal.
• Verify the dishwasher model number against the part compatibility list before installation.

Pro Tip

Part Details

Key Features

• Genuine Whirlpool OEM part
• Lower/door-bottom orientation
• Approximate dimensions: 23.4 in long, 2.5 in wide, 1.55 in high

Installation Notes

• Disconnect electrical power before servicing the dishwasher.
• Confirm the exact appliance model before ordering or installing.
• After installation, keep the door closed for several hours to help the seal seat.

Verified Compatible Models

2213222N414, 2213229N414, 2214523N611, 2214545N711, 2214573N612, 2214715N710, 2214743N513, 2214792N512, 2214793N512, 2214815N612, 66512762K314, 66512772K314, 66512773K314, 66512774K314, 66512779K314, 66513229N413, 66513542N412, 66513542N414, 66513543N413, 66514522N610, 66514523N610, 66514543N711, 66514545N711, 66514549N710, 66514562N611, 66514563N610, 66514565N611, 66514569N610, 66514572N611, 66514573N610, 66514573N612, 66514579N610, 66514579N612, 66514742N510, 66514742N512, 66514743N510, 66514743N512, 66514749N510, 66514749N512, 66514752N510, 66514753N510, 66514754N510, 66514754N512, 66514759N511, 66514762N510, 66514792N512, 66514792N513, 66514812N611, 66514813N610, 66514815N610, BLB14DRANA4, GLB14BBANA0, JDTSS246GM0, KDFE104DBL2, KDFE104DBL3, KDFE104DBL4, KDFE104DBL5, KDFE104DSS2, KDFE104DSS3, KDFE104DSS4, KDFE104DSS5, KDFE104DWH2, KDFE104DWH3, KDFE104DWH4, KDFE104DWH5, KDFE104HBL0, KDFE104HWH1, KDFE204EBL1, KDTE104EBL4, KDTE204EBL1, KDTE204GPS1, KDTE254EBL2, KDTE554CSS4, KDTM404ESS3, MDB4949SDE2, MDB4949SDH3, MDB4949SHW1, MDB8959SFH3, WDF760SADT3, WDF770SAFZ2, WDT920SADE2, WDT970SAHZ0, 66514815N611, 66514793N511, 66514793N513, 66514799N510, 66514799N513, 66514812N610, KDFE104HWH0, KDTM404EBL3, KDTM404EWH3, MDB4949SDH2, WDF560SAFB0, WDF560SAFB1, WDF560SAFB2, WDF560SAFM0, WDF560SAFM1

Fitment reminder: Match the complete appliance model number, including suffix or revision where applicable, before ordering.
