DISHWASHER DOES NOT DRAIN
GE (General Electric) Dishwasher Drain Solenoid and Bracket Assembly WD21X10268, Fixes Dishwasher does not drain
Genuine GE dishwasher drain solenoid and bracket assembly that operates the drain-valve mechanism to permit dishwasher draining.
Part WD21X10268Replaces WD21X10071, 1263990, 165D5478P002GE (General Electric)
Guaranteed to Fit — or your money back.
Confirm your full appliance model number before ordering.
Confirm your full appliance model number before ordering.
Is This the Right Part?
Part NumberWD21X10268
ReplacesWD21X10071, 1263990, 165D5478P002
ManufacturerGE (General Electric)
Appliance TypeDishwasher
Part TypeDrain Solenoid and Bracket Assembly
✅ Cross Reference Information
Current Part NumberWD21X10268
ReplacesWD21X10071, 1263990, 165D5478P002
Common Symptoms
- Dishwasher does not drain
- Drain-valve mechanism does not actuate during the drain cycle
Check Before Replacing
- With power disconnected, inspect the solenoid, bracket, wiring, and drain-valve linkage for visible damage or disconnection.
- During a service test, observe whether the solenoid actuates the drain-valve mechanism when the dishwasher enters drain; follow the appliance service documentation for testing procedures.
Pro Tip
Verify the complete dishwasher model number before ordering because this assembly applies only to specific models.
Part Details
Part NumberWD21X10268
Part TypeDrain Solenoid and Bracket Assembly
ManufacturerGE (General Electric)
Appliance TypeDishwasher
Primary FunctionActuates the dishwasher drain-valve flapper during the drain portion of the cycle.
Installation Notes
- Disconnect electrical power before servicing the dishwasher.
- Access to the assembly is generally through the lower dishwasher area; use the appliance service documentation for model-specific removal and installation instructions.
- Reconnect wiring exactly as originally installed and verify the drain-valve linkage moves freely.
Verified Compatible Models
ADW1100N00BB, ADW1100N00WW, ADW1100N10BB, ADW1100N10WW, ADW1100N15BB, ADW1100N15WW, ADW1100N20BB, ADW1100N20WW, ADW1100N30BB, ADW1100N30WW, ADW1100N35BB, ADW1100N35WW, GHDA350N00BB, GHDA350N00WW, GHDA350N10BB, 36314031000, 36314032000, 36314038000, 36314039000, 36314071794, 36314072795, 36314074794, 36314075794, 36314081993, 36314151000, 36314152000, 36314158000, 36314159000, 36314191992, 36314191993
Fitment reminder: Match the complete appliance model number, including suffix or revision where applicable, before ordering.
