Whirlpool Range Surface burner igniter / spark electrode (IGNTR-SURF) W11628654, Replaces W10892340

Genuine Whirlpool OEM surface-burner ignition component used to produce the ignition spark for selected Whirlpool-family gas ranges. Manufacturer catalog wording also identifies it as a spark electrode.

Is This the Right Part?

✅ Cross Reference Information

Common Symptoms

• No visible spark at the affected burner electrode
• Delayed ignition after turning the burner knob to Lite
• Weak or intermittent ignition after a spill or cleaning
• Surface burner fails to light even though other burners operate normally

Check Before Replacing

• With the burner controls off and the appliance cool, confirm the burner cap and base are seated correctly and centered.
• Inspect the electrode tip and ceramic insulator for visible moisture, grease, heavy residue, cracks, or breakage.
• After ensuring the area is fully dry, observe from a safe position while briefly turning the affected burner to Lite; check whether a spark is visible at the electrode tip. Do not touch the burner, electrode, or metal parts while energized.
• If the burner clicks but does not light, verify that the burner ports are clean and that the gas supply is available; these conditions can mimic an electrode failure.
• If the affected burner has no spark while other burners spark normally, inspect the electrode lead connection only with power disconnected and the controls off.

Pro Tip

Part Details

Key Features

• Genuine Whirlpool OEM surface-burner ignition component
• Manufacturer catalog name: Spark Electrode
• Whirlpool designation: IGNTR-SURF
• Used at selected surface-burner positions depending on the range model
• Documented Whirlpool replacement for W10892340

Installation Notes

• Disconnect electrical power and shut off the gas supply before servicing the range.
• Allow the appliance and burner components to cool completely before removal or installation.
• Use the model-specific service documentation to identify the correct burner position and electrode lead connection; the exact mounting arrangement varies by range model.
• Do not bend, crack, or otherwise alter the ceramic insulator or electrode tip during installation.
• After installation, restore utilities and verify ignition from a safe position; if ignition remains abnormal, stop using the burner and have the appliance inspected.

Verified Compatible Models

BDR90ARNNA00, KCGC500JSS00, KCGC506JSS00, KCGC558JSS00, KFDC500JIB01, KFDC500JSC00, KFDC500JSS00, KFDC506JAV03, KFDC506JBK01, KFDC506JBK03, KFDC506JSC00, KFDC506JSS00, KFDC558JAV00, KFDC558JMH01, KFDC558JPA01

Fitment reminder: Match the complete appliance model number, including suffix or revision where applicable, before ordering.
