Whirlpool Corporation Range Display Board / Display Assembly W11128223, Replaces W10759323

Genuine Whirlpool OEM range display board/display assembly used for the user interface and display functions on select Whirlpool-family ranges, including KitchenAid models.

Is This the Right Part?

✅ Cross Reference Information

Common Symptoms

• No clock or timer display
• Missing, dim, or flickering display digits
• Display does not show temperature or cooking-mode information
• Display controls do not respond

Check Before Replacing

• Verify the range has power by checking the dedicated breaker and confirming that other range functions respond; reset the breaker once if appropriate.
• Observe whether the display is completely blank, dim, missing individual digits, or intermittent.
• Check whether the range’s buttons or controls respond while the display is affected; do not assume the display board is at fault if the entire appliance is without power.
• If service access is required, disconnect power at the breaker before inspecting the display-board wiring or connectors, and use the model-specific service documentation.

Pro Tip

Part Details

Key Features

• Genuine Whirlpool OEM display board/display assembly
• Designed for selected Whirlpool-family ranges, including KitchenAid models
• Displays time, temperature, and appliance-status information
• Supports the user-interface functions associated with the range display and controls

Installation Notes

• Disconnect electrical power at the breaker before servicing.
• Use the model-specific service or installation instructions because access and connector locations vary by range model.
• Handle the electronic assembly carefully and avoid stressing its wiring or connectors.
• Replace all removed panels and covers before restoring power and operating the range.

Verified Compatible Models

KSDB900ESS2, KSDB900ESS3, KSDB900ESS4, KSDB900ESS5, KSDB900ESS6, KSDB900ESS8, KSDB900ESS9, KSGB900ESS2, KSGB900ESS3, KSGB900ESS4, KSGB900ESS5, KSGB900ESS6, KSGB900ESS8, KSIB900ESS1, KSIB900ESS3

Fitment reminder: Match the complete appliance model number, including suffix or revision where applicable, before ordering.
