W11162115 Whirlpool Right-Front Surface Element Switch for Ranges, Fixes Burner Stuck on High or Not Heating
Right-front burner stuck on high, not heating, or not responding to the control knob? W11162115 is a genuine Whirlpool surface-element infinite switch used in select Whirlpool and Amana electric ranges and cooktops. It replaces discontinued Whirlpool part number W10600015. The switch controls the right-front surface element on applicable models by cycling electrical power according to the control-knob setting. Published specifications identify the switch as a 240-volt, 2600-watt surface-element control. ⚡ Common failure point in Whirlpool-built electric ranges. Part W11162115 is the genuine OEM replacement that may restore burner heat control when diagnosis confirms the original switch is defective.
❓ Is This the Right Part?
This is the correct fix if ALL of the following are true:
- ✔ Range or cooktop powers on and other burners function normally
- ✔ Electrical supply to the appliance is confirmed and adequate
- ✔ Surface element, wiring and terminals have been inspected
- ✔ ONLY problem is the right-front burner not regulating, stuck on high, or not heating
Important: Confirm the complete appliance model, burner position, element configuration, shaft style and terminal arrangement before ordering. Similar-looking Whirlpool switches may control different burner positions or wattages and are not interchangeable. A defective switch is one possible cause of a burner that does not regulate, remains on high or does not heat — similar symptoms can also result from a failed surface element, burned wiring, damaged terminals, an incorrect electrical supply or another burner-control component.
Not sure? Send us your model number — we'll confirm before you order.
🔧 Common Symptoms
- Right-front burner remains on high regardless of knob position
- Right-front burner does not heat at all
- Burner heats intermittently or cycles incorrectly
- Burner does not respond to changes in the control setting
- Control knob turns freely but burner output does not change
✔ If these symptoms match and the switch has been confirmed as the failed component, W11162115 is the OEM replacement for compatible models and burner positions.
✔ Regulates electrical power to the compatible surface element when operating correctly.
📦 Part Details
- Part Number: W11162115
- Replaces: W10600015 (verified discontinued Whirlpool OEM service number)
- Type: Surface-element infinite switch — right-front burner control, 240V, 2600W
- Distributor / Catalogue References: 4546345, AP6278156, EAP12347916, PS12347916, AWP43118, PD00047070, HD12347916, WHIW11162115
- Brands: Whirlpool, Amana and affiliated Whirlpool-manufactured brands
- Condition: New Genuine OEM
- Note: Do not substitute the left-front, rear-element or single-element switch based only on appearance — confirm by complete model number and burner position
While the control panel is open, inspect the wiring harness and terminals connected to the switch for heat damage, corrosion or loose connections. Burned terminals are a common secondary cause of burner control problems and should be repaired before installing the new switch. Also confirm the surface element itself is functional before replacing the switch.
⚙️ Installation
Skill Level: Moderate — 20 to 40 minutes. Disconnect the range or cooktop from electrical power at the circuit breaker before opening the control panel or handling switch wiring. Remove the control knob, access the rear of the control panel, disconnect the wiring harness from the old switch and remove the mounting hardware. Install the new switch, reconnect the wiring harness in the original configuration and confirm all terminals are fully seated. Restore power and test all burner positions before reassembly. Installation procedures and required tools vary by appliance model.
✓ Compatible Models
Independently verified (33 models): ACC6340KFB00, ACC6340KFW00, ACC6356KFB01, ACC6356KFW01, IEL730CS0, IEL730CS1, IEL730CS2, WCE55US6HB00, WEC310S0LB0, WEC310S0LB1, WEC310S0LB2, WEC310S0LB3, WEC310S0LS0, WEC310S0LS1, WEC310S0LS2, WEC310S0LS3, WEC310S0LW0, WEC310S0LW1, WEC310S0LW2, WEC310S0LW3, WEC530H0DB0, WEC530H0DS0, WEC530H0DW0, WEE730H0DB0, WEE730H0DS0, WEE730H0DW0, YACS4303MFS0, YACS4303MFS1, YACS4303MFW0, YACS4303MFW1, YIEL730CS0, YIEL730CS1, YIEL730CS2.
Additional Whirlpool-family models are pending two-source verification. Contact us to verify your model number before ordering. Confirm the complete appliance model, burner position, element configuration, shaft style and terminal arrangement.
💡 Pro Tip
Surface-element switches can have multiple terminals and the wiring configuration varies by model. Before removing the old switch, photograph the terminal layout and wire positions from multiple angles. Incorrect wiring after replacement is the most common cause of a burner that still does not work correctly after the switch is installed.
✓ Model-Specific Repair Pages
✅Compatibility & Cross Reference
Not sure about your model number? Call 1-877-899-7278 and we’ll help you confirm. All brand names are the property of their respective owners and are used for compatibility reference only.
