LG Refrigerator Evaporator Assembly 5421JJ1001T

LG refrigerator evaporator assembly and sealed-system heat exchanger that cools the refrigerator.

Is This the Right Part?

Common Symptoms

• Refrigerator compartment not cooling adequately

Check Before Replacing

• Verify that the refrigerator is not cooling while other basic operating checks have been completed.
• Confirm the appliance model and complete suffix before ordering because evaporator assemblies are model-specific.
• Have a qualified sealed-system technician evaluate the evaporator and refrigerant circuit before replacement.

Pro Tip

Part Details

Key Features

• Genuine LG evaporator assembly
• Sealed-system heat exchanger
• Schematic location 301A on documented model parts diagrams

Installation Notes

• Disconnect power before servicing the refrigerator.
• This repair involves the sealed refrigerant system and should be performed by a qualified service technician.
• Refrigerant must be recovered and the system recharged as required after sealed-system work.

Verified Compatible Models

GM-B223DKNM.ASBCNA4, GM-B223DKXM.ASBCNA3, GM-B223DKXM.ASBCNA4, GM-B223DKXM.ASBCNA5, GM-B223DSNL.ASTCNA4, GM-B223DSXM.ASTCNA4, GM-B223DSXM.ASTCNA5, GM-B223DSXM.ASTCNA6, GM-B223RSNM.ASTCNA5, GM-B223RSNM.ASTCNA6, GM-F223DSTB.ASTCNA0, GM-F223DSXM.ASTCNA3, GM-F223DSXM.ASTCNA4, GM-F223DSXM.ASTCNA5, GM-F223RSXM.ASTCSE5, LCFS22EXS.ASTCNA0, LFC22770ST.ASTCNA5, LFCS22520S.ASTCNA5, LFCS22520S/05, LFDS22520S.ASTCNA3, LFDS22520S.ASTCNA4, LFDS22520S.ASTCNA5, LFDS22520S/04, LFNS22520S.ASTCNA4, LRFNS2200S.ASTCNA1, LRFNS2200W.ASWCNA5

Fitment reminder: Match the complete appliance model number, including suffix or revision where applicable, before ordering.
