Is This the Part You Need?
The dryer thermostat monitors and regulates the air temperature inside the drum. When it fails — from age, heat cycling fatigue, or a blocked exhaust vent causing sustained overtemperature — the dryer either runs too hot and scorches clothes, or the thermal cutout trips and the dryer produces no heat at all. A failed thermostat won’t self-reset and will keep the dryer non-functional until replaced. The AGM30045804 is the OEM LG replacement that restores accurate temperature regulation across the DLG and DLGX gas dryer lineup.
Symptoms This Part Fixes
- Dryer runs but produces no heat
- Dryer overheating — clothes coming out too hot or scorched
- Thermal cutout (thermal fuse) tripping repeatedly
- Dryer takes multiple cycles to dry a normal load
- Dryer shuts off mid-cycle before clothes are dry
- Dryer runs on air-only even when heat is selected
Part Details
- Part Number: AGM30045804
- Replaces (Cross-Reference): 6931EL3003C, 6931EL3004B
- Brand: LG (OEM)
- Type: Dryer Thermostat
- Compatible Appliance: LG Gas Dryers (DLG / DLGX series)
- HS Code: 850990
- Condition: New OEM
Installation Notes
Skill Level: Beginner-Intermediate — requires removing the dryer back panel or front panel depending on model to access the thermostat mounting location.
- Disconnect power and shut off the gas supply before starting
- The thermostat is typically located on the exhaust duct or burner housing — consult your model’s parts diagram to confirm location
- Note wire terminal positions before disconnecting — photograph the existing thermostat before removal
- Do not overtighten mounting screws — the thermostat housing can crack
- After installation, run a timed dry cycle and verify heat output before reassembling panels
Compatible Models
Fits a wide range of LG gas dryer models across the DLG and DLGX series, including:
79002, 79272, 90021, 90141, 90147, 90311, 90441, 91028, 91029, 91072, 91073, 91182, 91382, 91383, 91582, 91583, CDG3389WD, CDG3389WN, DLG1320W, DLG1502W, DLG2141W, DLG2251W, DLG2302, DLG2351W, DLG2524W, DLG2526W, DLG2532, DLG3051W, DLG3171W, DLG3501W, DLG3744D, DLG3744S, DLG3744U, DLG3744W, DLG3788W, DLG5932W, DLG5966G, DLG5966S, DLG5966W, DLG5988W, DLG5988WM, DLG6988W, DLG7188RM, DLG7188WM, DLG8388NM, DLG8388WM, DLG9588WM, DLGX0002TM, DLGX2502V, DLGX255, DLGX2802L, DLGX2902V, DLGX3002P, DLGX3471V, DLGX3571V, DLGX3886C, DLGX5001V, DLGX5171V, DLGX5681V, DLGX5781VE, DLGX7188RM, DLGX7188WM, DLGX7601VE, DLGX8001V, DLGX8388NM, DLGX8388WM, DLGX9001V, DLGY1202W, DLGY1702V, GDP1329CGS2
Contact us with your full model number to confirm compatibility before ordering.
A failed thermostat is often what caused the thermal fuse to blow in the first place. If your dryer has no heat and you’ve already replaced the thermal fuse, the thermostat is the next part to test — a faulty thermostat that allowed overtemperature will blow the new fuse again within days if not replaced at the same time. Test the thermostat for continuity with a multimeter: it should read closed (continuity) at room temperature. An open reading confirms failure. Also inspect and clean the exhaust vent run before reassembling — a blocked vent is the root cause of most thermostat and thermal fuse failures on LG dryers.
✓ Model-Specific Repair Pages
✅Compatibility & Cross Reference
Not sure about your model number? Call 1-877-899-7278 and we’ll help you confirm. All brand names are the property of their respective owners and are used for compatibility reference only.
