Bosch Dishwasher Door Lock / Door Latch And Switch Assembly 00630783, Replaces 10025890, 630783 – Superseded by 10028963

Genuine Bosch dishwasher door lock assembly, also described as a door latch and switch assembly. It secures the dishwasher door during operation and helps prevent operation when the door is not properly closed.

Is This the Right Part?

✅ Cross Reference Information

Common Symptoms

• Door does not latch or stay securely closed.
• Dishwasher will not begin a cycle even though the control panel has power.
• Dishwasher may stop mid-cycle if the latch or door-closed signal disengages.
• Door may require unusual force to close or may not produce a firm latch engagement.

Check Before Replacing

• With power disconnected, visually inspect the latch for cracking, deformation, or obvious wear.
• Check that the door striker aligns with the latch and that the door closes fully without obstruction.
• Inspect the door seal and hinges for displacement or damage that could prevent proper latch engagement.
• Close the door normally and confirm that the latch engages securely; do not force or bypass the safety switch.
• If the dishwasher still will not start, follow the model-specific Bosch troubleshooting procedure rather than assuming the latch is defective.

Pro Tip

Part Details

Key Features

• Genuine Bosch lock kit / door latch and sensor assembly.
• Bosch identifies replacement part 10028963 as the replacement for 00630783 and 10025890.
• Bosch describes the replacement as a 47N door latch / sensor lock kit and states that both parts in the kit must be replaced.
• The assembly combines the mechanical door-locking function with door-closed sensing.

Installation Notes

• Disconnect electrical power before servicing the dishwasher.
• Use the model-specific Bosch service information or parts diagram for access and installation details.
• Replace the complete latch/sensor kit as specified by Bosch; do not assume the latch and sensor should be serviced separately.
• After installation, verify that the door closes and latches normally before returning the dishwasher to operation.
• Do not bypass or defeat the door-safety switch.

Verified Compatible Models

SHE3AR52UC, SHE3AR55UC, SHE3AR56UC, SHE3AR72UC, SHE3AR72UC/24, SHE3AR72UC/25, SHE3AR72UC/26, SHE3AR72UC/27, SHE3AR72UC/28, SHE3AR75UC, SHE3AR75UC/24, SHE3AR75UC/25, SHE3AR75UC/26, SHE3AR75UC/27, SHE3AR75UC/28

Fitment reminder: Match the complete appliance model number, including suffix or revision where applicable, before ordering.
