✅ This part is also sold as WG03F00154 and G5097976 — same component, different OEM part number.

Built-In Refrigerator Not Cooling or Compressor Failed? Compressor W10841139 – Fix Sealed System Fast

Name: W10841139 Whirlpool Refrigerator Compressor – Genuine OEM | XPart Supply Canada
Brand: Whirlpool
SKU: W10841139
Price: 984.97 CAD
Availability: InStock

A built-in refrigerator that has completely stopped cooling, has a compressor that won’t start, or is short-cycling with no temperature recovery has a failed sealed system — and the compressor is the most common root cause. In most Whirlpool, KitchenAid, Jenn-Air, and Maytag built-in column and side-by-side refrigerators, the compressor W10841139 is the heart of the sealed cooling system — pressurizing refrigerant to drive the entire cooling cycle. When it fails, the refrigerant circuit stops, temperatures rise, and no amount of control board or fan replacement will restore cooling. ⚡ The definitive sealed-system repair for Whirlpool-platform built-in refrigerators. Part W10841139 is the genuine OEM compressor that restores full sealed-system operation and gets your refrigerator cooling again.

❓ Is This the Right Part?

This is the correct fix if ALL of the following are true:

✔ Your refrigerator powers on — fans, lights, and control board are operational
✔ The condenser and evaporator fans are running normally
✔ Refrigerant charge has been verified — no leak detected in the sealed system
✔ The inverter board or start relay has been tested and confirmed functional
✔ ONLY problem is the compressor not starting, short-cycling, or confirmed mechanically seized

Not sure? Send us your model number — we’ll confirm before you order.

🔧 Common Symptoms

Refrigerator not cooling at all — most common search: “KitchenAid built-in fridge not cold”
Compressor clicks on then immediately shuts off — short-cycling every few minutes
Compressor completely silent — no attempt to start during cooling cycle
Compressor hot to the touch and tripping thermal overload
Loud clicking, buzzing, or grinding from the compressor compartment at startup
All fans running normally but no cooling — sealed system confirmed not pressurizing

✔ If these symptoms match, this is the most likely failed component in the system.

✔ In most cases, replacing this compressor restores full sealed-system cooling operation.

📦 Part Details

Part Number: W10841139
Type: Sealed System Compressor – Whirlpool-Platform Built-In Refrigerator
Replaces: OEM direct-fit compressor — supersedes 12002741, 2208937, 2223393, 2302967, 4388999, 67004630, 8201575, W10173296, W10181763 (no modification required)
Brands: Whirlpool, KitchenAid, Maytag, Amana, Jenn-Air

⚠️ Recommended While Repairing:
When replacing a compressor, always replace the filter-drier and flush the sealed system — a contaminated system will destroy a new compressor within weeks. Evacuate to 500 microns or below before recharging with the correct refrigerant type and charge weight specified on the unit’s data plate.

⚙️ Installation

Skill Level: Advanced — EPA 608 Certification Required. Professional installation strongly recommended. Recover all refrigerant before opening the sealed system — venting refrigerant is illegal under Canadian and US environmental regulations. Replace the filter-drier, braze the new compressor W10841139 into the sealed system, evacuate to 500 microns minimum, and recharge with the correct refrigerant type and weight from the unit’s data plate. Leak-test all joints before returning the unit to service. This is not a DIY repair — improper sealed system work will void the compressor warranty and can result in repeat failure within days.

💡 Pro Tip

Diagnose the Start Relay Before Ordering a Compressor:
A failed start relay mimics a dead compressor — the compressor clicks and won’t start, but the sealed system is fine. Shake the relay: if it rattles, it’s failed. A start relay costs under $20 and takes 5 minutes to replace. Confirm the relay is good before committing to a $480 compressor replacement — it’s the most common misdiagnosis on this platform.

Model hub pages: KBFC42FSS00, KBFC42FTS00, KSSC36FKS00, KSSC42FKS00, KSSC48FKS00, KSSS36FKX00, KSSS42FKX00, KSSS48FKX00, KSSO42FMX00, KSSO48FMX00, JS42NXFXDW00, JS48NXFXDW00, KBSN602ESS00, KBSN608ESS00, KSSV42FMS00

✓ Model-Specific Repair Pages

REFRIGERATOR

✅Compatibility & Cross Reference

Part number W10841139 replaces 12002741, 2208937, 2223393, 2302967, 4388999, 67004630, 8201575, W10173296, W10181763

DYF42BIWS00, DYF42BNDI00, DYF48BIWS00, DYF48BNDI00, EF42BDCBSS, EF42BNDBSS, EF42DBSS, EF42NBSS, EF48BDCBSS, EF48BNDBSS, EF48DBSS, GC5SHGXKB00, GC5SHGXKB01, GC5SHGXKQ00, GC5SHGXKQ01, GC5SHGXKS00, GC5SHGXKS01, GC5SHGXKT00, GC5SHGXKT01, GC5SHGXLB00, GC5SHGXLB01, GC5SHGXLQ00, GC5SHGXLQ01, GC5SHGXLS00, GC5SHGXLS01, GC5SHGXLT00, GC5SHGXLT01, GC5THGXKB00, GC5THGXKB01, GC5THGXKQ00, GC5THGXKQ01, GC5THGXKT00, GC5THGXKT01, GC5THGXLB00, GC5THGXLB01, GC5THGXLQ00, GC5THGXLQ01, GC5THGXLS00, GC5THGXLS01, GC5THGXLT00, GC5THGXLT01, IF42BDCBOL, IF42BNDBOL, IF48BDCBOL, IF48BNDBOL, JF42CXFXDB00, JF42CXFXDB01, JF42NXFXDW00, JF42NXFXDW01, JF42NXFXDW02, JF42NXFXDW03, JF42NXFXDW04, JF42PPFXDB00, JF42PPFXDB01, JF42SEFXDB00, JF42SEFXDB01, JF42SSFXDA00, JF42SSFXDA01, JF42SSFXDA02, JS42CXDBDB00, JS42CXDUDB00, JS42CXDUDB02, JS42CXFXDB00, JS42NXFXDW00, JS42NXFXDW01, JS42NXFXDW02, JS42NXFXDW03, JS42NXFXDW04, JS42NXFXDW05, JS42PPDUDB00, JS42PPDUDB01, JS42PPDUDB02, JS42PPDUDB14, JS42PPDUDB15, JS42PPDUDB16, JS42PPDUDB20, JS42PPFXDB00, JS42SEDUDB00, JS42SEDUDB01, JS42SEDUDW00, JS42SEDUDW01, JS42SEDUDW12, JS42SEDUDW13, JS42SEDUDW14, JS42SEDUDW15, JS42SEDUDW20, JS42SEFXDB00, JS48CXDBDB00, JS48CXDBDB01, JS48CXDBDB13, JS48CXDUDB00, JS48CXFXDB00, JS48CXFXDB01, JS48NXFXDW00, JS48NXFXDW01, JS48NXFXDW02, JS48NXFXDW03, JS48NXFXDW04, JS48NXFXDW05, JS48PPDUDB00, JS48PPDUDB01, JS48PPDUDB02, JS48PPDUDB13, JS48PPDUDB14, JS48PPDUDB15, JS48PPDUDB16, JS48PPDUDB20, JS48PPFXDB00, JS48SEDUDB00, JS48SEDUDB01, JS48SEDUDW00, JS48SEDUDW12, JS48SEDUDW14, JS48SEDUDW15, JS48SEDUDW20, JS48SEDUEA01, JS48SEDUEA02, JS48SEFXDB00, KBFC42FSS00, KBFC42FTS00, KBFC42FTS02, KBFC42FTS03, KBFC42FTS04, KBFC42FTS05, KBFC42FTS06, KBFC42FTS07, KBFC42FTS08, KBFO42FSX00, KBFO42FTX00, KBFO42FTX02, KBFO42FTX03, KBFO42FTX04, KBFO42FTX05, KBFO42FTX06, KBFO42FTX07, KBFO42FTX08, KBLC36FKB00, KBLC36FKB01, KBLC36FKB02, KBLC36FKS00, KBLC36FKS01, KBLC36FKS02, KBLC36FMS00, KBLC36FMS01, KBLC36FMS02, KBLO36FMX00, KBLO36FMX01, KBLO36FMX02, KBLP36FKS00, KBLP36FKS01, KBLP36FKS02, KBLP36FMS00, KBLP36FMS01, KBLP36FMS02, KBLS36FKB00, KBLS36FKB01, KBLS36FKB02, KBLS36FKT00, KBLS36FKT01, KBLS36FKT02, KBLS36FKW00, KBLS36FKW01, KBLS36FKW02, KBLS36FKX00, KBLS36FKX01, KBLS36FKX02, KBLS36FMB00, KBLS36FMB01, KBLS36FMB02, KBLS36FMX00, KBLS36FMX01, KBLS36FMX02, KBLV36FPM01, KBLV36FPM02, KBLV36FPS01, KBLV36FPS02, KBRC36FKB00, KBRC36FKB01, KBRC36FKB02, KBRC36FKS00, KBRC36FKS01, KBRC36FKS02, KBRC36FKU00, KBRC36FKU01, KBRC36FKU02, KBRC36FMS00, KBRC36FMS01, KBRC36FMS02, KBRO36FMX00, KBRO36FMX01, KBRO36FMX02, KBRP36FKS00, KBRP36FKS01, KBRP36FKS02, KBRP36FMS00, KBRP36FMS01, KBRP36FMS02, KBRS36FKB00, KBRS36FKB01, KBRS36FKB02, KBRS36FKT00, KBRS36FKT01, KBRS36FKT02, KBRS36FKW00, KBRS36FKW01, KBRS36FKW02, KBRS36FKX00, KBRS36FKX01, KBRS36FKX02, KBRS36FMB00, KBRS36FMB01, KBRS36FMB02, KBRS36FMX00, KBRS36FMX01, KBRS36FMX02, KBRV36FPM01, KBRV36FPM02, KBRV36FPS01, KBRV36FPS02, KBSN508ESS00, KBSN602EBS00, KBSN602EPA00, KBSN602ESS00, KBSN608EBS00, KBSN608EPA00, KBSN608ESS00, KBUDT4265E, KBUDT4265E04, KBURT3665E01, KLBP36FKS01, KSBP25FKSS00, KSBP25FKSS01, KSBP25FKSS02, KSBS25FKBL00, KSBS25FKBL01, KSBS25FKBL02, KSBS25FKBT00, KSBS25FKBT01, KSBS25FKBT02, KSBS25FKSS02, KSBS25FKWH00, KSBS25FKWH01, KSBS25FKWH02, KSCS25FKBL01, KSCS25FKBL02, KSCS25FKBT01, KSCS25FKBT02, KSCS25FKSS00, KSCS25FKSS01, KSCS25FKSS02, KSCS25FKWH01, KSCS25FKWH02, KSFS25FKBL00, KSFS25FKBL01, KSFS25FKBL02, KSFS25FKBT00, KSFS25FKBT01, KSFS25FKBT02, KSFS25FKWH00, KSFS25FKWH01, KSFS25FKWH02, KSSC36FKB00, KSSC36FKB01, KSSC36FKB02, KSSC36FKS00, KSSC36FKS01, KSSC36FKS02, KSSC36FMS00, KSSC36FMS01, KSSC36FMS02, KSSC36FMS03, KSSC36FTS00, KSSC36FTS02, KSSC36QKS00, KSSC36QKS01, KSSC36QKS02, KSSC36QMS00, KSSC36QMS01, KSSC36QMS02, KSSC36QMS03, KSSC36QTS00, KSSC36QTS02, KSSC42FKB00, KSSC42FKB01, KSSC42FKB02, KSSC42FKS00, KSSC42FKS01, KSSC42FKS02, KSSC42FMS00, KSSC42FMS01, KSSC42FMS02, KSSC42FMS03, KSSC42FTS00, KSSC42FTS02, KSSC42FTS03, KSSC42FTS04, KSSC42FTS15, KSSC42FTS16, KSSC42FTS17, KSSC42FTS18, KSSC42QKS00, KSSC42QKS01, KSSC42QKS02, KSSC42QMS00, KSSC42QMS01, KSSC42QMS02, KSSC42QMS03, KSSC42QMU00, KSSC42QMU01, KSSC42QTS00, KSSC42QTS02, KSSC42QTS03, KSSC42QTS18, KSSC42QVS00, KSSC42QVS06, KSSC48FKB00, KSSC48FKB01, KSSC48FKB02, KSSC48FKS00, KSSC48FKS01, KSSC48FKS02, KSSC48FMS00, KSSC48FMS01, KSSC48FMS02, KSSC48FMS03, KSSC48FTS00, KSSC48FTS02, KSSC48FTS03, KSSC48FTS04, KSSC48FTS15, KSSC48FTS16, KSSC48FTS17, KSSC48FTS18, KSSC48FTS20, KSSC48QKS00, KSSC48QKS01, KSSC48QKS02, KSSC48QMS00, KSSC48QMS01, KSSC48QMS02, KSSC48QMS03, KSSC48QTS00, KSSC48QTS02, KSSC48QTS03, KSSC48QVS00, KSSC48QVS01, KSSC48QVS02, KSSC48QVS03, KSSC48QVS04, KSSC48QVS05, KSSC48QVS06, KSSO36FMX00, KSSO36FMX01, KSSO36FMX02, KSSO36FMX03, KSSO36FTX00, KSSO36FTX02, KSSO36QMB00, KSSO36QMB01, KSSO36QMB02, KSSO36QMB03, KSSO36QMW00, KSSO36QMW01, KSSO36QMX01, KSSO36QMX02, KSSO36QTB00, KSSO36QTB02, KSSO36QTX00, KSSO36QTX02, KSSO42FMX00, KSSO42FMX01, KSSO42FMX02, KSSO42FMX03, KSSO42FTX00, KSSO42FTX02, KSSO42FTX03, KSSO42FTX04, KSSO42FTX15, KSSO42FTX16, KSSO42FTX17, KSSO42FTX18, KSSO42QMB00, KSSO42QMB01, KSSO42QMB02, KSSO42QMB03, KSSO42QMW00, KSSO42QMW01, KSSO42QMX01, KSSO42QMX02, KSSO42QTB00, KSSO42QTB02, KSSO42QTB03, KSSO42QTB04, KSSO42QTX00, KSSO42QTX02, KSSO42QTX03, KSSO42QTX04, KSSO48FMX00, KSSO48FMX01, KSSO48FMX02, KSSO48FMX03, KSSO48FTX00, KSSO48FTX02, KSSO48FTX03, KSSO48FTX04, KSSO48FTX15, KSSO48FTX16, KSSO48FTX17, KSSO48FTX18, KSSO48FTX20, KSSO48QMB00, KSSO48QMB01, KSSO48QMB02, KSSO48QMB03, KSSO48QMW00, KSSO48QMW01, KSSO48QMX01, KSSO48QMX02, KSSO48QTB00, KSSO48QTB02, KSSO48QTB03, KSSO48QTB04, KSSO48QTX00, KSSO48QTX02, KSSO48QTX03, KSSO48QTX04, KSSP36QKS00, KSSP36QKS01, KSSP36QKS02, KSSP36QMS00, KSSP36QMS01, KSSP36QMS02, KSSP36QMS03, KSSP36QTS00, KSSP36QTS02, KSSP42QKS00, KSSP42QKS01, KSSP42QKS02, KSSP42QMS00, KSSP42QMS01, KSSP42QMS02, KSSP42QMS03, KSSP42QTS00, KSSP42QTS02, KSSP48QKS00, KSSP48QKS01, KSSP48QKS02, KSSP48QMS00, KSSP48QMS01, KSSP48QMS02, KSSP48QMS03, KSSP48QTS00, KSSP48QTS02, KSSS36FKB00, KSSS36FKB01, KSSS36FKB02, KSSS36FKT00, KSSS36FKT01, KSSS36FKT02, KSSS36FKW00, KSSS36FKW01, KSSS36FKW02, KSSS36FKX00, KSSS36FKX01, KSSS36FKX02, KSSS36FMB00, KSSS36FMB01, KSSS36FMB02, KSSS36FMX00, KSSS36FMX01, KSSS36FMX02, KSSS36FMX03, KSSS36FTX00, KSSS36FTX02, KSSS36QKB00, KSSS36QKB01, KSSS36QKB02, KSSS36QKT00, KSSS36QKT01, KSSS36QKT02, KSSS36QKW00, KSSS36QKW01, KSSS36QKW02, KSSS36QKX00, KSSS36QKX01, KSSS36QKX02, KSSS36QMB00, KSSS36QMB01, KSSS36QMB02, KSSS36QMB03, KSSS36QMW00, KSSS36QMW01, KSSS36QMW02, KSSS36QMW03, KSSS36QMX00, KSSS36QMX01, KSSS36QMX02, KSSS36QMX03, KSSS36QTB00, KSSS36QTB02, KSSS36QTW00, KSSS36QTW02, KSSS36QTX00, KSSS36QTX02, KSSS42FKB00, KSSS42FKB01, KSSS42FKB02, KSSS42FKT00, KSSS42FKT01, KSSS42FKT02, KSSS42FKW00, KSSS42FKW01, KSSS42FKW02, KSSS42FKX00, KSSS42FKX01, KSSS42FKX02, KSSS42FMB00, KSSS42FMB01, KSSS42FMB02, KSSS42FMX00, KSSS42FMX01, KSSS42FMX02, KSSS42FMX03, KSSS42FTX00, KSSS42FTX02, KSSS42FTX03, KSSS42FTX04, KSSS42QKB00, KSSS42QKB01, KSSS42QKB02, KSSS42QKT00, KSSS42QKT01, KSSS42QKT02, KSSS42QKW00, KSSS42QKW01, KSSS42QKW02, KSSS42QKX00, KSSS42QKX01, KSSS42QKX02, KSSS42QMB00, KSSS42QMB01, KSSS42QMB02, KSSS42QMB03, KSSS42QMW00, KSSS42QMW01, KSSS42QMW02, KSSS42QMW03, KSSS42QMX00, KSSS42QMX01, KSSS42QMX02, KSSS42QMX03, KSSS42QTB00, KSSS42QTB02, KSSS42QTB03, KSSS42QTB04, KSSS42QTW00, KSSS42QTW02, KSSS42QTW03, KSSS42QTW04, KSSS42QTX00, KSSS42QTX02, KSSS42QTX03, KSSS42QTX04, KSSS48FKB00, KSSS48FKB01, KSSS48FKB02, KSSS48FKT00, KSSS48FKT01, KSSS48FKT02, KSSS48FKW00, KSSS48FKW01, KSSS48FKW02, KSSS48FKX00, KSSS48FKX01, KSSS48FKX02, KSSS48FMB00, KSSS48FMB01, KSSS48FMB02, KSSS48FMX00, KSSS48FMX01, KSSS48FMX02, KSSS48FMX03, KSSS48FMXO3, KSSS48FTX00, KSSS48FTX02, KSSS48FTX03, KSSS48FTX04, KSSS48QKB00, KSSS48QKB01, KSSS48QKB02, KSSS48QKT00, KSSS48QKT01, KSSS48QKT02, KSSS48QKW00, KSSS48QKW01, KSSS48QKW02, KSSS48QKX00, KSSS48QKX01, KSSS48QKX02, KSSS48QMB00, KSSS48QMB01, KSSS48QMB02, KSSS48QMB03, KSSS48QMW00, KSSS48QMW01, KSSS48QMW02, KSSS48QMW03, KSSS48QMX00, KSSS48QMX01, KSSS48QMX02, KSSS48QMX03, KSSS48QTB00, KSSS48QTB02, KSSS48QTB03, KSSS48QTB04, KSSS48QTW00, KSSS48QTW02, KSSS48QTW03, KSSS48QTW04, KSSS48QTX00, KSSS48QTX02, KSSS48QTX03, KSSS48QTX04, KSSV42FMM00, KSSV42FMM01, KSSV42FMM02, KSSV42FMS00, KSSV42FMS01, KSSV42FMS02

Not sure about your model number? Call 1-877-899-7278 and we’ll help you confirm. All brand names are the property of their respective owners and are used for compatibility reference only.
