Whirlpool User Control and Display Board / Range Electronic Control Board W11339761, Replaces W11293148, W11113847, W10854343

Genuine Whirlpool OEM upper console control assembly for ranges. The assembly houses the electronic control board and display and allows selection of time and temperature settings. Retailer technical descriptions also identify it as a control board that monitors temperature and controls oven heat.

Is This the Right Part?

✅ Cross Reference Information

Common Symptoms

• Range will not start
• Controls will not program
• Touchpad does not respond
• Oven display or console functions fail
• Oven produces no heat or insufficient heat
• Oven door lock operation may be intermittent when the lock circuit and motor test correctly

Check Before Replacing

• Confirm the appliance model and existing part number before replacing the assembly; similar-looking control assemblies may not interchange.
• Disconnect electrical power to the range before inspecting the console assembly, wiring harness, or connectors.
• After power is safely disconnected, visually inspect accessible connectors and wiring for looseness, damage, corrosion, or signs of moisture; do not assume the control board is defective from symptoms alone.
• If the complaint involves an oven door lock, verify the lock motor and its wiring according to the appliance-specific service documentation before attributing the fault to the control assembly.
• Restore power only after all panels and connections are properly secured, then verify display, touch controls, programming, heating, and related functions.

Pro Tip

Part Details

Key Features

• Genuine Whirlpool OEM assembly
• White console assembly
• Combines the user control/display interface with electronic range-control functions
• Monitors temperature-related operation and controls oven heat
• Listed by Whirlpool as replacing W11293148 and W11113847
• Retailer technical descriptions also identify W10854343 as a replaced number

Installation Notes

• Disconnect electrical power before servicing the range.
• Use the appliance-specific service documentation for console removal, connector locations, and reassembly; no standalone installation instructions were identified for W11339761.
• Transfer or reconnect wiring only with power disconnected, and match each connector to its original location.
• Reassemble all panels and secure the console before restoring power or operating the range.
• Verify normal display, touch-control, programming, heating, and applicable door-lock operation after installation.

Verified Compatible Models

WEE750H0HB0, WEE750H0HB1, WEE750H0HB4, WEE750H0HB5, WEE750H0HW0, WEE750H0HW1, WEE750H0HW4, WEE750H0HW5, YWEE750H0HB0, YWEE750H0HB1, YWEE750H0HB4, YWEE750H0HB5, YWEE750H0HW0, YWEE750H0HW1, YWEE750H0HW4

Fitment reminder: Match the complete appliance model number, including suffix or revision where applicable, before ordering.
