OEM Replacement | Replaces W10916242, W11261210, W11316054 | Fast Shipping Across Canada
The W11354542 is the OEM direct-drive motor stator assembly for compatible Whirlpool front-load washers. The stator is the stationary coil pack mounted under the tub; it works with the rotor to create a rotating magnetic field that drives the basket for wash agitation and high-speed spin. Failures are typically caused by open or shorted windings, heat damage, moisture intrusion, or harness connector overheating. Important: Many stator failures are secondary to a failing harness connector, rotor damage, or water intrusion from a tub seal leak — inspect the root cause before installing the new stator. OEM replacement parts are not affiliated with, sponsored by, or endorsed by Whirlpool or any OEM manufacturer.
Washer won’t agitate, washer won’t spin, loud hum with no drum movement, weak or intermittent spin, burning smell from motor area, repeated motor or drive error codes, washer fills and drains but won’t move.
OEM Part Number: W11354542 | Replaces: W10916242, W11261210, W11316054 | Appliance Type: Front-Load Washer | Component: Motor Stator Assembly | Direct fit for compatible Whirlpool models.
W11354542 | W10916242 | W11261210 | W11316054
Unplug the washer before starting. This is a heavy under-unit repair — tip the washer back or lay it on its front to access the stator. Remove the rotor first (center bolt), then unbolt the stator from the tub bearing housing. Disconnect the wiring harness. Before installing the new stator, inspect the harness connector and rotor for damage. Estimated repair time: 45–90 minutes. Safety note: Always unplug before servicing.
7MMHW6621HC0, 7MMHW6621HW0, MHW6630HC0, MHW6630HW0, MHW8630HC0, MHW8630HC1, MHW8630HW0, MHW8630HW1, WFW8620HC0, WFW8620HC1, WFW8620HC2, WFW8620HW0, WFW8620HW1, WFW8620HW2, WFW9620HBK0, WFW9620HBK1, WFW9620HC0, WFW9620HC1, WFW9620HW0, WFW9620HW1. Contact us with your model number to confirm fit before ordering.
Does W11354542 replace W10916242? Yes — W11354542 is the current OEM part number and directly replaces W10916242, W11261210, and W11316054.
Is this a DIY repair? Advanced difficulty — requires tipping the washer and working under the unit. Estimated time: 45–90 minutes. Contact us if you need guidance.
Not sure about your model number? Call 1-877-899-7278 and we’ll help you confirm. All brand names are the property of their respective owners and are used for compatibility reference only.
