Whirlpool Washer Inner Tub (Spin Basket) W11513243, Replaces W11459626

Genuine Whirlpool washer inner tub/spin-basket assembly. The perforated basket holds the laundry load inside the washer during operation and spin cycles.

Is This the Right Part?

✅ Cross Reference Information

Common Symptoms

• Washer damages or tears clothing during agitation or spin
• Washer vibrates or shakes when the basket is damaged or distorted
• Water leakage may occur if the basket is broken or damaged

Check Before Replacing

• Unplug the washer and shut off the water supply before inspection or service.
• With the washer empty, visually inspect the basket interior, rim, and perforations for cracks, distortion, corrosion, or sharp projections.
• Run a clean cloth carefully along the accessible interior surface; if it catches on a sharp projection, the basket may be damaged.
• Rotate the empty basket by hand and observe for obvious rubbing, scraping, or visible wobble; do not operate the washer with a visibly damaged basket.
• Confirm that suspected basket damage is not instead caused by an obstruction, suspension problem, washplate, hub, or other related component.

Pro Tip

Part Details

Key Features

• Genuine Whirlpool OEM inner-tub/spin-basket assembly
• Perforated basket design permits water flow through the laundry load
• Designed to hold and spin the laundry during washer cycles
• Whirlpool basket assembly designation: "Basket Asm - Jrny 4.8 Psc."
• Replaces Whirlpool part number W11459626

Installation Notes

• Disconnect electrical power and shut off the water supply before installation.
• Wear work gloves when handling the basket to protect against sharp edges.
• Verify the complete washer model before ordering because fitment is model-specific.
• Follow the model-specific service or installation instructions; the available part listing does not provide universal part-specific installation steps.

Verified Compatible Models

8TWTW5057PW1, 110.21112022, 110.31312021, 110.31312022, MVW5430MW0, MVW5430MW1, MVW5430MW2, MVW5430PBK0, MVW5430PBK1, MVW5435PBK0, MVW5435PBK1, MVW5435PW0, MVW6200KW2, MVW6200KW3, MVW6200KW4, MVW6230HC2, MVW6230HC3, MVW6230HC4, MVW6230HC5, MVW6230HW2, MVW6230HW3, MVW6230HW4, MVW6230HW5, MVW6230RHW2, MVW6230RHW3, MVW6230RHW4, MVW6230RHW5, MVW6500MBK0, MVW6500MBK1, MVW6500MW0, WTW5057LW0, WTW5057LW1, WTW5100HC2, WTW5100HC3, WTW5100HC5, WTW5100HW2, WTW5100HW3, WTW5100HW6, WTW5105HC2, WTW5105HC3, WTW5105HC4, WTW5105HC5, WTW5105HW2, WTW5105HW3, WTW5105HW4, WTW5105HW6, WTW6120HC2, WTW6120HC3, WTW6120HW2, WTW6120HW3

Fitment reminder: Match the complete appliance model number, including suffix or revision where applicable, before ordering.
