OVERHEATING-RELATED SHUTDOWN OR INADEQUATE HEATING
Whirlpool Range/Stove/Oven; Microwave; Oven/Microwave Combo Fixed thermostat (THRMST-FIX) W11568584, Fixes Overheating-related shutdown or inadequate heating
Genuine Whirlpool OEM fixed thermostat used in select Whirlpool-family microwave, range/stove/oven, and oven/microwave-combination appliances. The part is identified by Whirlpool parts retailers as THRMST-FIX.
Part W11568584Replaces W10389447Whirlpool
Guaranteed to Fit — or your money back.
Confirm your full appliance model number before ordering.
Confirm your full appliance model number before ordering.
Is This the Right Part?
Part NumberW11568584
ReplacesW10389447
ManufacturerWhirlpool
Appliance TypeRange/Stove/Oven; Microwave; Oven/Microwave Combo
Part TypeFixed thermostat (THRMST-FIX)
✅ Cross Reference Information
Current Part NumberW11568584
ReplacesW10389447
Common Symptoms
- Microwave or oven stops after running for a short time
- Microwave does not heat or heats inconsistently
- Cooling/exhaust fan does not operate when temperature rises
- Overheating or thermal-protection interruption
- Oven heating is insufficient or uneven
Check Before Replacing
- Confirm the appliance model number and verify that W11568584 is specified for that model before testing or replacing the part.
- Disconnect electrical power before accessing the thermostat.
- Visually inspect the thermostat, wiring, and terminals for looseness, discoloration, or heat damage without bypassing or jumping the safety device.
- With power disconnected, a qualified technician may check thermostat continuity according to the appliance-specific service documentation; lack of expected continuity can indicate an open thermostat, but other faults can produce the same symptom.
- For microwave installations, do not access internal components unless qualified, because high-voltage capacitors may retain a dangerous charge even after unplugging.
Pro Tip
Because this is a safety thermostat, do not bypass it or assume a no-heat symptom proves the thermostat is defective; verify the model-specific wiring and test procedure first, and investigate the underlying overheating cause if it has opened.
Part Details
Part NumberW11568584
Part TypeFixed thermostat (THRMST-FIX)
ManufacturerWhirlpool
Appliance TypeRange/Stove/Oven; Microwave; Oven/Microwave Combo
Primary FunctionFixed safety thermostat that monitors temperature and opens the circuit to limit overheating; in some Whirlpool-family microwave applications it also controls or enables the cooling/exhaust fan response.
Installation Notes
- Disconnect power before service and allow the appliance to cool completely.
- Use the appliance-specific service documentation for access, terminal identification, and continuity specifications.
- Do not bypass, modify, or substitute the thermostat with a device of different specifications.
- Microwave or combination-oven internal service should be performed by a qualified technician because of retained high-voltage electrical hazards.
- Verify the replacement part against the appliance model before installation.
Verified Compatible Models
WOC54EC0HB20, WOC54EC0HS00, WOC54EC0HS01, WOC54EC0HS20, WOC54EC0HW20, WOC54EC7AB00, WOC54EC7AB01, WOC54EC7AB02, WOC54EC7AB03, WOC54EC7HB00, WOC54EC7HB01, WOC54EC7HB04, WOC54EC7HB20, WOC54EC7HS20, WOC75EC0HS00
Fitment reminder: Match the complete appliance model number, including suffix or revision where applicable, before ordering.
