Whirlpool Gas Valve Solenoid / Dryer Gas Valve Coil Set WPW10328463, Fixes Dryer heats intermittently or stops heating after the burner initially ignites
Genuine Whirlpool OEM dryer gas-valve coil set (valve coil kit). The coils open the dryer's gas valves during operation.
Confirm your full appliance model number before ordering.
Is This the Right Part?
✅ Cross Reference Information
Common Symptoms
- Dryer tumbles but produces no heat when the gas burner fails to open.
- Dryer heats normally at first, then stops heating after the coils warm up.
- Burner igniter glows, but the gas flame does not ignite or does not remain on.
Check Before Replacing
- Confirm the dryer has gas supply and that the gas shutoff valve is open.
- Observe the burner through the appliance's designated viewing area, if provided: an igniter that glows but is followed by no gas ignition can indicate a gas-valve control problem, though other components may cause the same symptom.
- Verify the dryer is receiving power and that the igniter operates before attributing the symptom to the valve coils.
- Use the appliance's model-specific technical documentation for any electrical resistance testing; do not test or disassemble the gas valve assembly while connected to gas or power.
Pro Tip
Part Details
Installation Notes
- Unplug the dryer and shut off the gas supply before installation.
- Follow the model-specific parts diagram and service instructions because access and included coil components can vary by dryer.
- After installation, restore utilities carefully and check appliance operation according to the manufacturer's service instructions.
- Do not disturb gas piping or perform a gas-leak repair unless qualified to do so.
Verified Compatible Models
4GWGD4900YQ0, 4GWGD4900YQ5, 110.76002011, 1107012512, 1107062111, 1107072010, 1107192312, 11070012003, 11070102312, 11070172003, 11070222510, 11070222512, 11070222513, 11070222514, 11071202011, 11071202012, 11071252012, 11071262310, 11071262311, 11071402310, 11071402312, 11072332511, AGD4675YQ3, BSG17B6ANA0, CGT8000AQ1, EGD4400WQ1, LTG5243DQB, MDG17PRAWW2, MGD3100DW0, MGD5030MW1, MGD5100DW0, MGD6000AG0, MGD6000XG0, MGD7000XG2, MGD7000XR0, MGD7000XW1, MGD7020RW0, MGD8100DC1, MGD8630HW4, MGD9000YR1, MGD9000YW0, MGDE250XL1, MGDP575GW0, MGDX6STBW2, MGDX700XL1, MGDX700XW1, MLG24PDAWW2, WGD70HEBW0, WGD95HEDW0, WGD9550WL2
Fitment reminder: Match the complete appliance model number, including suffix or revision where applicable, before ordering.
