Whirlpool Range oven bake/broil igniter, horizontal mount with wire connector WP7432P136-60, Replaces 7432P136-60, 7432P131-60, 74008064, 32009801, 31991701

OEM gas-range oven bake/broil igniter. Horizontal-mount design with wire connector; may be used for either the bake or broil burner. Whirlpool parts documentation identifies it as an oven bake/broil igniter.

Is This the Right Part?

✅ Cross Reference Information

Common Symptoms

• Little or no heat during baking
• Igniter glows but the gas does not ignite
• Igniter does not glow
• Oven will not start or heat
• Element will not heat

Check Before Replacing

• With the oven controls off and the appliance safe to observe, watch whether the igniter glows during a bake or broil call.
• If the igniter glows for more than about 90 seconds without ignition, the igniter may be too weak to open the safety valve; do not assume this is the only possible cause.
• If the igniter does not glow, power must be disconnected before checking the igniter circuit and continuity with an appropriate meter; electrical testing should be performed only by someone qualified to do so.
• If gas is smelled without ignition, turn the oven off, ventilate the area, avoid flames or sparks, and arrange qualified service rather than repeatedly attempting ignition.

Pro Tip

Part Details

Key Features

• Whirlpool OEM range oven bake/broil igniter
• Horizontal-mount design
• Wire connector
• Can be used for either the bake or broil igniter where specified by the appliance model
• Manufacturer-listed replacement for 7432P136-60, 7432P131-60, 74008064, 32009801, and 31991701

Installation Notes

• Disconnect electrical power and shut off the range gas supply before service.
• Allow the oven and igniter to cool before handling.
• Use the appliance-specific service instructions to access the burner and igniter; mounting and access arrangements can vary by model.
• Handle the igniter element carefully because it is fragile, and do not touch the central element unnecessarily.
• Reconnect the wire connector securely and verify that wiring is not pinched or contacting hot surfaces before reassembling.
• After installation, restore utilities and check operation according to the appliance service instructions; if gas odor or ignition failure remains, stop and obtain qualified service.

Verified Compatible Models

ACF3315AK, ACF3315AK-PACF3315AK2, ACF3315AT, ACF3325AB, ACF3325AC, ACF3325AS, ACF3325AW-PACF3325AW0, ACF3375AC-PACF3375AC1, AGR5725RDB16, AGR5725RDQ16, AGR5725RDS, AGR5735QDW, MGR5765QDQ, MGR5765QDS, PGR5750LDQ

Fitment reminder: Match the complete appliance model number, including suffix or revision where applicable, before ordering.
