⚠️ GE Gas Range Burner Won't Ignite or Surface Controls Unresponsive — WS01F08276 Dual Switch Harness

WS01F08276 Replaces 295D1590G005 GE · GE Profile JCGB660 · JCGB735 · PCGB911 Series

WS01F08276 GE Gas Range Dual Switch Harness — Burner Won't Ignite, Clicks Constantly, or Surface Controls Fail

When the dual switch harness fails on a GE gas range, the result is immediate and disruptive — burners that won't ignite, controls that click continuously without lighting, or surface elements that are completely unresponsive. The WS01F08276 Oven Dual Switch Harness is the current genuine OEM replacement, superseding 295D1590G005, and restores proper ignition control and switch function to affected GE and GE Profile 30" gas ranges.

Symptoms This Part Fixes

  • One or more burners won't ignite when the knob is turned
  • Igniter clicks continuously even after the burner is lit
  • Surface burner controls feel loose, sticky, or unresponsive
  • Burner sparks on the wrong element when a knob is turned
  • No spark at all from one or more burner positions
  • Range trips a breaker or blows a fuse when ignition is attempted

Part Details

  • Part Number: WS01F08276
  • Replaces (Cross-Reference): 295D1590G005
  • Manufacturer: GE Appliances
  • Component: Dual switch harness — surface burner ignition control
  • Compatible Brands: GE, GE Profile
  • Condition: New — Genuine OEM
💡 Pro Tip — Check the Igniter Switches Before Replacing the Module:
Continuous clicking after the burner lights is almost always the switch harness, not the spark module. Before replacing the module, inspect the harness connectors for moisture, corrosion, or a stuck switch contact. A quick continuity test on each switch leg confirms which position has failed — saving you from replacing the wrong part.

Installation Notes

  • Skill Level: Intermediate DIY — basic hand tools required
  • Always disconnect power at the breaker and shut off the gas supply before beginning
  • Photograph all harness connector positions before disconnecting
  • Do not force connectors — align tabs carefully before seating
  • After reinstallation, restore power and test each burner position individually before closing up the range
  • Confirm no continuous clicking remains after burners are lit

Compatible Models

Fits the following GE and GE Profile 30" gas range models. Confirm your model number on the label inside the oven door frame or drawer before ordering.

  • JCGB660DP1WW, JCGB660SP1SS
  • JCGB735DP1WW, JCGB735EP1ES, JCGB735SP1SS
  • JCGB745SP1SS, JCGBS86SP1SS
  • JGB660SP1SS, JGB735SP1SS
  • PCGB911EEJ4ES, PCGB911EEJ5ES
  • PCGB911FEJ1DS, PCGB911FEJ2DS
  • PCGB911SEJ4SS, PCGB911SEJ5SS, PCGB911SEJ6SS
  • PGB911ZEJ4SS

✓ Model-Specific Repair Pages

GE JCGB745SP1SS Range Parts & Repair Guide GE JCGB735SP1SS Range Parts & Repair Guide GE JCGB735EP1ES Range Parts & Repair Guide GE JCGB735DP1WW Range Parts & Repair Guide PGB911ZEJ4SS JGB735SP1SS JGB660SP1SS JCGB660SP1SS JCGB660DP1WW

✅Compatibility & Cross Reference

295D1590G005

Not sure about your model number? Call 1-877-899-7278 and we’ll help you confirm. All brand names are the property of their respective owners and are used for compatibility reference only.
