LG Front-load washing machine Harness, Multi EAD35511503, Fixes Blank
LG multi-wire harness used in the dispenser assembly wiring for specified WM2016C*/01 washer variants.
Part EAD35511503LG
LG multi-wire harness used in the dispenser assembly wiring for specified WM2016C*/01 washer variants.
Is This the Right Part?
Part NumberEAD35511503
ManufacturerLG
Appliance TypeFront-load washing machine
Part TypeHarness, Multi
Check Before Replacing
- With power disconnected, inspect the harness and connectors for loose terminals, damaged insulation, corrosion, or visible wire breaks.
- Verify the harness connector routing and seating against the appliance wiring diagram before replacing the component.
Pro Tip
Confirm the complete washer model and the harness connector configuration before ordering; LG lists a different harness number for WM2016C* versus WM2016C*/01 variants.
Part Details
Part NumberEAD35511503
Part TypeHarness, Multi
ManufacturerLG
Appliance TypeFront-load washing machine
Primary FunctionProvides electrical connections within the dispenser assembly wiring circuit.
Key Features
- LG OEM part number EAD35511503
- Part description: Harness, Multi
- Shown at location F120 in the WM2016CW parts listing
- Associated with WM2016C*/01 in the service-manual wiring documentation
Installation Notes
- Disconnect electrical power before inspecting or replacing the harness.
- Route and secure the replacement harness exactly as the original to avoid pinching, abrasion, or connector strain.
- Match every connector and wire routing point before restoring power.
Verified Compatible Models
WM2016CW
Fitment reminder: Match the complete appliance model number, including suffix or revision where applicable, before ordering.
