Samsung Dryer Has No Power? Dryer Power Cord DC96-00762A — Fix Dead Dryer Fast
If your Samsung electric dryer has no power, trips the breaker repeatedly, or shows signs of a burnt or damaged cord at the wall connection, the power cord is the first component to inspect and replace. In Samsung electric dryers, the power cord (DC96-00762A) is the 4-wire 30A connection between your wall outlet and the dryer’s terminal block. When it fails — due to heat damage, a loose terminal, or physical wear — the dryer receives no power at all, or runs intermittently with breaker trips. ⚡ Common failure point when moving or reinstalling a dryer, or after years of heat cycling at the terminal block connection. Part DC96-00762A is the OEM Samsung 4-wire power cord that restores safe, code-compliant electrical connection to your dryer.
❓ Is This the Right Part?
This is the correct fix if ALL of the following are true:
- ✔ Wall outlet has been tested and confirmed live at 240V (NEMA 14-30R receptacle)
- ✔ Breaker is not tripped — or trips only when dryer is plugged in
- ✔ Dryer terminal block and internal wiring have been visually inspected and are intact
- ✔ ONLY problem is no power to dryer, intermittent power loss, or visible cord damage at plug or terminal end
Not sure? Send us your model number — we'll confirm before you order.
🔧 Common Symptoms
- Dryer completely dead — no display, no response to any button
- Breaker trips immediately or shortly after dryer is plugged in
- Visible burn marks, melting, or discolouration at the plug or cord end
- Intermittent power — dryer works sometimes but cuts out randomly
- Burning smell near the wall outlet or dryer connection point
✔ If these symptoms match, the power cord is the most likely failed component in the system.
✔ In most cases, replacing the DC96-00762A power cord restores full dryer operation immediately.
📦 Part Details
- Part Number: DC96-00762A
- Type: Dryer Power Cord — 4-Wire, 30A, 240V, NEMA 14-30P plug
- OEM Brand: Samsung
- Fits: Samsung electric dryers with 4-wire outlet configuration (NEMA 14-30R)
- Available As: OEM (New) and Used
- HS Code: 850990 | Country of Origin: Canada
While the cord is disconnected, inspect the terminal block (DC96-00882A) inside the dryer — a burnt or corroded terminal block is often the root cause of cord failure and will destroy a new cord if not replaced at the same time. A $15 terminal block can prevent a repeat failure and a potential fire hazard.
⚙️ Installation
Skill Level: EASY — 15–25 minutes. Disconnect power at the breaker before servicing. Remove the access panel on the rear of the dryer to expose the terminal block. Disconnect the three or four wires from the old cord, noting wire positions (or photograph before removal). Connect the new 4-wire cord — green/bare to ground, white to centre neutral, black and red to outer terminals — tighten all screws firmly, secure the strain relief clamp, and restore power to test.
✓ Compatible Models
Compatible with select Samsung electric dryer models requiring a 4-wire 30A power cord connection. Contact us to verify your model number before ordering — cord compatibility depends on your wall outlet configuration (3-wire vs. 4-wire).
💡 Pro Tip
North American homes built before 2000 often have 3-wire dryer outlets (NEMA 10-30R), while homes built after 2000 use 4-wire outlets (NEMA 14-30R). The DC96-00762A is a 4-wire cord. If your wall outlet has 3 slots (no separate ground), you need a 3-wire cord instead. Check your outlet before ordering — or contact us and we’ll confirm the right cord for your setup.
✅Compatibility & Cross Reference
Not sure about your model number? Call 1-877-899-7278 and we’ll help you confirm. All brand names are the property of their respective owners and are used for compatibility reference only.
