Whirlpool Maytag Washer Lid Lock W11670519 — Fixes Won't Start or Spin

A defective lid lock is one possible cause of a Whirlpool or Maytag top-load washer that will not start or spin. W11670519 is a genuine Whirlpool washer lid-lock and latch assembly used in select Whirlpool, Maytag and Crosley top-load washers. It replaces discontinued Whirlpool part number W11368616. The assembly detects when the washer lid is closed and locks the lid during applicable portions of the wash and spin cycles. A defective lid lock may contribute to a washer that will not start, will not spin, repeatedly clicks, stops during a cycle or displays a lid-lock-related fault. ⚡ Complete the model-specific diagnostic procedure before replacing the lid lock. Part W11670519 may restore operation when diagnosis confirms that the original lid lock is defective.

🇺🇸 Matching U.S. Part Number: W11670519

❓ Is This the Right Part?

This is the correct fix if ALL of the following are true:

• ✔ Washer powers on and the control panel responds normally
• ✔ Water supply hoses are connected and pressure is adequate
• ✔ Lid strike (W11513250) is intact and properly aligned
• ✔ Wiring harness and connector to the lid lock are undamaged
• ✔ Model-specific diagnostic confirms the lid lock assembly is defective

Not sure? Send us your model number — we'll confirm before you order.

🔧 Common Symptoms

• Washer will not start — pressing Start does nothing after lid is closed
• Washer fills with water but will not agitate or spin
• Washer stops mid-cycle and lid lock indicator flashes
• Lid lock clicks repeatedly but washer never advances
• Lid-lock-related fault code displayed (confirm code applies to your exact model)

✔ Similar symptoms can also result from a damaged lid strike, broken wiring, a loose connector, control-board failure, drain-system problem, motor fault or another safety-circuit condition.

✔ May restore operation when diagnosis confirms that the original lid lock assembly is defective.

📦 Part Details

• Part Number: W11670519
• Type: Washer lid-lock and latch assembly — detects lid closure and locks lid during wash and spin
• Replaces: W11368616 (verified discontinued Whirlpool service number)
• Brands: Whirlpool, Maytag, Crosley (Whirlpool-built top-load washers)
• Condition: New — Genuine OEM
• Note: W11513250 is the separate lid strike and is not included with this assembly. Confirm the complete washer model — visually similar Whirlpool lid locks can use different wiring, connectors, voltage ratings or mounting arrangements.

⚙️ Installation

Skill Level: Easy to Moderate — time varies by model. Disconnect electrical power before accessing the washer cabinet. The lid lock assembly is typically mounted under the washer lid at the rear or side of the cabinet opening. Access procedures vary by model — refer to your model's service manual for disassembly specifics. Disconnect the wiring harness, remove the mounting screws, swap in the new W11670519, reconnect, and run a short test cycle to confirm normal operation.

✓ Compatible Models

Confirmed compatible with MVW4505MW0, MVW4505MW1, MVW4505MW2, MVW5035MW1, MVW5035MW2, MVW5430MW0, MVW5430MW1, MVW5430MW2, MVW5430PBK0, MVW5430PBK1, MVW5435PBK0, MVW5435PBK1, MVW5435PW0, MVW5435PW1, WTW5100HW6, WTW5105HW6, WTW6150PW1, WTW6157PB1, WTW8127LC3, WTW8127LW3, ZWW5310RB1. Contact us to verify your model number before ordering. Confirm the complete model suffix and revision — visually similar Whirlpool lid locks can use different wiring, connectors or mounting arrangements.
