Whirlpool Dishwasher Upper dishrack stop clip WP8565925, Replaces 8565925

Whirlpool OEM stop clip for the upper dishwasher dishrack. It prevents the upper rack from sliding completely off its support rail.

Is This the Right Part?

✅ Cross Reference Information

Common Symptoms

• Upper rack stop clip is broken, missing, loose, or no longer locks onto the rail.
• Upper dishrack can be pulled out of the dishwasher track.
• Rack movement is not properly limited at the front or rear rail ends.

Check Before Replacing

• With the dishwasher unloaded and the rack pulled out carefully, inspect the rail-end stop clips for cracks, missing pieces, or looseness.
• Gently pull the upper rack toward the open door and verify that the stop clips engage and prevent the rack from leaving the rails.
• Check both sides of the upper rack and confirm that the clips are installed in the same intended rail-stop locations.
• If the rack still drops or binds after the clips are secure, inspect the rack wheels, adjusters, and rails separately rather than assuming the stop clip is the cause.

Pro Tip

Part Details

Key Features

• Whirlpool genuine OEM upper dishrack stop clip.
• Limits upper-rack travel at the rail end.
• Uses a retaining-tab/locking design on compatible dishwasher tracks.
• Small plastic rack component intended for replacement when cracked, missing, or loose.

Installation Notes

• Disconnect power to the dishwasher before servicing and remove dishes from the rack.
• Follow the appliance model's rack-removal instructions if the upper rack must be taken out.
• For the documented Whirlpool track-stop design, release the retaining tab, remove the old stop, position the replacement from underneath the track, rotate it into place, and press it until the retaining tab locks.
• After installation, gently test the rack against the stop and verify that the clip is locked before loading dishes.

Verified Compatible Models

66513482K902, 66513484K902, 66513489K902, 66513542N412, 66513804N710, ADB1500ADB1, ADB1500ADS1, ADB1500ADW1, CDB7000AWB1, DU900PWKB0, DU900PWKQ0, DU900PWKT0, MDB4629AWB1, MDB4629AWS1, MDB4629AWW1

Fitment reminder: Match the complete appliance model number, including suffix or revision where applicable, before ordering.
